Installation of options

56
Optional functionality may be added to the SX90 sonar.
All options are pre-programmed into the standard sonar version,
and that Simrad offer a 1 month free test period for certain
options. When ordering a permanent option installation, a code
word will be released from Simrad. For a free test, or permanent
option installation, use the following procedures.
To access the Install Options dialog
1 Select the
Setup
Click the button to open the
2
Test
3 Click the
Installation Menu
4 Observe that the installation menu bar is shown on the top
of the screen.
5 Click
Options →Install options
6 Observe that the
Install Options parameter dialog
The following parameters are available in the
parameter dialog.
• : This field displays the unique 12-character hardware
HWID
identification code. This code is different for each SX90 sonar.
Simrad uses this code to generate the 32-character code word
used for a permanent option installation.
• : Each will start the 1 month free test period for the chosen
Try
option.
Note
If any time or date adjustments are made during the test
period, the option will be closed.
•
Add License String
installation of the chosen option. When you press the button,
this will activate the on-screen keyboard used to type the
required 32-character code word.
To add an option permanently
1 Open the
Install Options
the number.
HWID
menu.
System test
button.
.
parameter dialog opens.
Install Options
: This button is used for permanent
parameter dialog, and write down
menu.
Install options
