Cleaning The Transducer - Simrad SX90 - REFERENCE MANUAL REV D Reference Manual

307670/D
8 Check that no power penetrates through the top of the
transducer shaft sleeve.
• If water is penetrating, you need to add lubricant. Refer
to Hull unit lubrication on page 208.
Check that the Hull Unit is clean, and that no excessive
9
grease is present.
10 Set the mode selector switch
11 Observe that the transducer array is hoisted up from the
water.
• The hoist/lower motor will automatically stop when the
transducer shaft reaches the upper limit switch.
12 Check that the array is hoisted properly, that the transducer
cable is not tangled in any way, and that no other objects
interfere with the operation.
13 If necessary, remove dust and salt water residue with a soft
cloth moistened in fresh water. Do not use strong solvents.
14 If necessary, remove rust and apply suitable protective paint.
15 Check the air bleeding system. Refer to Air bleeding on
page 207.
16 Set the mode selector switch
17 Close and secure the Motor Control Unit.
18 Connect the mains power to the Processor Unit.
19 Remove the warning label on the Operating Panel.
Related topics
• Motor Control Unit familiarization on page 198

Cleaning the transducer

The transducer normally needs little attention. However, the
transducer face should be inspected and cleaned when docking.
Note
Do not paint the transducer array with traditional hull plating
paint. Use only the correct type of paint approved by Simrad.
Do not use metal tools or high pressure water on the transducer
array.
Procedure
1 Ensure that the distance between the vessel hull and the
bottom of the dry dock is sufficient to lower the transducer
array.
2 In the Motor Control Unit, set the mode selector switch
to position LOWER.
On-board maintenance
to position HOIST.
S302
to position REMOTE.
S302
S302
205
