Edit Gear (Trawl) - Simrad SX90 - REFERENCE MANUAL REV D Reference Manual

307670/D

Edit Gear (Trawl)

The parameter dialog opens when you click the
Gear
on the menu. Each of the available options in the
Setup
dialog can be edited using the
selected, this
Edit Gear
These parameters allows you to monitor or define the distance
and depth of your trawl, as well as the height and width of
your trawl opening. If you use the Simrad ITI system, these
parameters will be provided automatically.
Options
: Click to define the distance to the trawl. The setting is
Distance
automatically if you click the
trawl system is connected to the sonar. If you click
can define the distance in steps of 10 meters.
: Click to define the depth of the trawl. The setting is made
Depth
automatically if you click the
trawl system is connected to the sonar. If you click
can define the depth in steps of 10 meters.
: Click to define the height of the trawl opening. The
Height
setting is made automatically if you click the
provided that a Simrad trawl system is connected to the sonar. If
you click , you can define the height in steps of 1 meter.
Manual
: Click to define the width of the trawl opening. The setting
Width
is made automatically if you click the
a Simrad trawl system is connected to the sonar. If you click
, you can define the width in steps of 10 meters.
Manual
: Click to define the length of the trawl symbol on the
Length
sonar display.
: Click to close the parameter dialog.
Close
: Click to access the on-line help.
Help
Related topics
Setup menu on page 89
Gear on page 133
button. When a trawl has been
Edit
parameter dialog is provided.
button, provided that a Simrad
Auto
button, provided that a Simrad
Auto
button, provided that
Auto
Parameters
