OPERATING PANEL

307670/D
This chapter describes the Simrad SX90 Operating Panel.
The frequently used functions are directly accessible by the
designated control buttons on the Operating Panel, and may
enter operational commands directly. The buttons are grouped in
fields according to their purpose. Most sonar functions are also
accessible and activated using the menu system on the display
and the trackball and
Figure 26 SX90 Operating Panel
Topics
• 'Main switch' field on page 72
• 'Symbol' field on page 73
• 'Mode' field on page 75
• 'Gain' field on page 75
• 'Range' field on page 76
• 'Cursor' field on page 76
• 'Train' field on page 77
• 'Tilt' field on page 79
• 'Various' field on page 80
button on the Operating Panel.
Select
Operating panel
71
