Simrad SX90
164

Status

The parameter dialog is by default displayed in the lower,
Status
right hand corner of the screen. The
not be closed, but if an other dialog is opened it will place itself
on top. The dialog contains a transducer position indicator,
Status
as well as read-outs of current time, date, latitude, longitude,
heading and speed.
Options
: Click to access the
Transducer
manual control of the hull unit.
: Read-out of current heading.
[Compass]
: Read-out of local time. Click to open the
[Time]
dialog box, which allows you to change the date and
properties
time settings.
: Read-out of local date. Click to open the
[Date]
dialog box, which allows you to change the date and
properties
time settings.
: Read-out of current geographical position.
[Position N]
: Read-out of current geographical position.
[Position E]
(Heading): Read-out of current vessel heading in a
Hdg
numerical value. Click to enter manual heading.
(Speed): Read-out of current vessel speed. Click to enter
Spd
manual speed.
: Read-out of current messages. The button changes
[Message]
colour to reflect the importance of the message. Click the button
to acknowledge. For additional details about the message, open
the .
Message Bar
Related topics
Transducer on page 172
Date and time properties on page 121
Heading on page 134
Speed on page 162
Date and time properties on page 121
Message Bar on page 138
parameter dialog can
Status
parameter dialog for
Transducer
Date and time
Date and time
