Panel Backlight

The parameter dialog opens when you click the
Panel Backlight
button on the
Panel Backlight
This parameter dialog controls the illumination on the keyboard
on the Operating Panel in 8 steps (0 – 7). Note that the backlight
can only be manually operated. The
future expansion.
The following options are available in the
parameter dialog:
• + (plus): Click to increase the backlight intensity.
• – (minus): Click to decrease the backlight intensity.
• : Click to allow manual control of the backlight
Manual
intensity.
• : Not used.
Auto
• : Click to close the parameter dialog.
Close
• : Click to access the on-line help.
Help
Related topics
Display menu on page 88
menu.
Display
button is added for
Auto
Panel Backlight
Parameters
145
