Parameters
• : When this function is selected, all echoes
Erase Echoes
displayed on the sonar view will be deleted.
• : When this function is selected, window areas
Make Same Size
tiled vertically will acquire the same width.
• : This command changes the display from
Grey scale data
a colour presentation to a black-and-white. The number of
shades of grey and the number of different colours used will
be the same. The grey scale presentation can be selected for
singular sonar views independent of each other. Click one
more time to restore the colours.
• : When this function is selected menus will be
View Menu
displayed according to the view in which the cursor is situated.
Several different
View

Object pop-up menu

The pop-up menu is accessed using the
Object
the trackball on the Operating Panel, or the right mouse button
if an optional computer mouse is installed. This pop-up menu is
mainly used when you operate the sonar from an optional mouse,
as most of the functions on it can be selected directly on the
Operating Panel. Note that the cursor related selections in the
pop-up menu use the cursor position where the pop-up
Object
menu was activated.
For more information about the
see 'Cursor' field on page 76.
When you open the
positioned over a defined object on the display, it will display
additional parameters.
• Inspect [object]
• Delete [object]
• Make [object] priority target
menus are available.
on the Operating Panel,
Object
pop-up menu with the cursor
Object
Menu descriptions
button over
Object
99
