  • Page 1 Installation manual Simrad SD570 Fishery sonar www.simrad.com A L W A Y S T H E F O R E F R O N T T E C H N O L O G Y...
  • Page 3 Simrad SD570 Fishery sonar Installation manual 851- -160085 / Rev.B...
  • Page 4 Note Simrad AS makes every effort to ensure that the information contained within this document is correct. However, our equipment is continuously being improved and updated, so we cannot assume liability for any errors which may occur. Warning The equipment to which this manual applies must only be used for the purpose for which it was designed.

  • Page 5: Installation Procedures

    Installation manual Sections This book is the Installation manual for the SD570 fishery sonar. It describes how to install the various units used by the SD570 system. Introduction This section gives a brief description of the SD 570/SE 570 sonars and the installation requirements.
  • Page 6 Simrad SD570 Remarks References Further information about the SD570 system may be found in the following manuals: • SD570 Operator manual The reader This Installation manual is intended for the design and installation engineers at the shipyard performing the installation. The information is supplied as the basis for the shipyard’s own installation drawings applicable to the vessel.
  • Page 7 Installation manual Document revisions Checked by Approved by Written by Date Sign Date Sign Date Sign Unknown 02.02.04 02.02.04 02.02.04 Sect Title Revision File Cover and contents 851--160085 Introduction 851--160115 Installation procedures 851--160116 Start--up procedures 851--160117 Trunk system 851--160503 Drawings 851--160118 Appendices 851--160675...
  • Page 8 Simrad SD570 Blank page 851-160085 / B...
  • Page 9 Installation manual High voltage safety warning Precautionary measures 2 Open his mouth and check for and remove any false teeth, chewing gum etc. The voltages used to power this equipment 3 Check if the victim is breathing. If not, are potentially lethal. Even 110 volts can kill. check if his heart is beating.
  • Page 10 Simrad SD570 Artificial respiration Remove the victim to a hospital as soon as possible, but do not interrupt the artificial 1 Kneel besides the victim’s head. Place one respiration and ECM cycles till his heart beat hand under his neck and lift, allowing his and breathing returns.
  • Page 11 Introduction 851- 160115 / AA000 / 3- 11 Introduction This section gives a brief description of the SD 570 / SE 570 sonars installation requirements. 851--160115 / B...
  • Page 12 Simrad SD570 / Base version Document revisions Date Written by Checked by Approved by Unknown 03.01.01 (The original signatures are recorded in the company’s logistic database) 851--160115 / B...

  • Page 13: Table Of Contents

    Introduction Table of contents INSTALLATION DOCUMENT ........SUPPLY CONDITIONS .
  • Page 14 Simrad SD570 / Base version Document history (The information on this page is for internal use) Rev.A Original issue for Base version. Rev.B Document transferred to Interleaf. No changes made to text or illustra- tions. 851--160115 / B...

  • Page 15: Installation Document

    Introduction 1 INSTALLATION DOCUMENT This installation manual will act as an installation document for later updating and service on the sonar, and must therefore be stored on board the vessel into which the equipment is to be installed. To ensure the best possible result of the installation, it is important that each procedure is carefully followed.

  • Page 16: Supply Conditions

    The Hull Unit uses an installation trunk which is equal to the old Simrad SL and SX installation trunks. The Hull Unit can therefore easily be mounted in an old SL or SX trunk. As an option, an adapter flange can be delivered for mounting the Hull Unit in an old SK, SB or SQ trunk.
  • Page 17 Introduction SQ & SB2 Adapter flange ..... . SD5- 112642 SK3 Adapter flange ......SD5- 112643 The cable between the Sonar Control Unit in the wheelhouse and the Transceiver Unit in the sonar room (see figure 1) can be...
  • Page 18 Simrad SD570 / Base version Figure 1 - SD 570 / SE 570 sonar system 851--160115 / B...

  • Page 19: Installation Procedures

    If damage to the equipment is discovered, the recipient should notify the carrier and Simrad so that Simrad can arrange for replacement or repair of the damaged equipment. 851--160115 / B...
  • Page 20 Simrad SD570 / Base version The equipment, once unpacked, must be stored inside in a room with an atmosphere free from corrosive agents. In addition, the equipment must be covered to protect it from dust and other forms of contamination.

  • Page 21: General Requirements

    Introduction 3 GENERAL REQUIREMENTS Responsibility and approbation The Hull Unit of the sonar is generally approved by The Norwegian Veritas (Organization for classification and registry of shipping). An approval of the installation must, however, be applied for in each case to the local maritime authority. The ship owner and the shipyard are responsible for the application.

  • Page 22: Auxiliary Equipment

    • Serial line, standard NMEA 0183; RS232, RS422 or Current loop. Echo sounder: In order to get a depth indication on the catch control page on the sonar, one of the following Simrad echo sounders can be connected: • EQ50, EQ55, EQ100, ES60, ES380 series, ES500 (RS232 serial line).

  • Page 23: Technical Specifications

    Introduction Technical specifications Table 1 comprises the specifications required for the installation. For further details, refer to the Operator Manual. Sonar Control Transceiver Unit Hull Unit Unit Voltage, nominal 115/230VAC 115/230 VAC 230/380/440 VAC Single phase* Single phase** 3--phase*** Voltage deviation ±15% of nominal ±15% of nominal 230V:±15%...

  • Page 24: Weights And Dimensions

    Simrad SD570 / Base version Weights and dimensions Weight SD 570 Weight SE 570 Dimensions Sonar Control 28 kg 28 kg See figure 2 Unit Transceiver Unit 75 kg 70 kg See figure 3 Hull Unit 275 kg 265 kg...
  • Page 25 Introduction Figure 2 - Outline dimensions of the Sonar Control Unit 851--160115 / B...
  • Page 26 Simrad SD570 / Base version Figure 3 - Outline dimensions of the Transceiver Unit 851--160115 / B...
  • Page 27 Introduction Figure 4 - Outline dimensions of the Hull Unit 851--160115 / B...
  • Page 28 Simrad SD570 / Base version Figure 5 - Outline dimensions of the optional trunk 851--160115 / B...
  • Page 29 Introduction 851- 160116 / AA000 / 3- 11 Installation procedures This section provides the necessary information for the installation and cabling of the complete SD 570/ SE 570 sonar systems according to Simrad’s requirements. 851--160116 / B...
  • Page 30 Simrad SD570 / Base version Document revisions Date Written by Checked by Approved by Unknown 03.01.01 (The original signatures are recorded in the company’s logistic database) 851--160116 / B...
  • Page 31 Introduction Table of contents INSTALLATION PLANNING ........General .
  • Page 32 Simrad SD570 / Base version Connecting a speed log with serial line output ... . Connecting other auxiliary equipment ......
  • Page 33 Introduction Document history (The information on this page is for internal use) Rev.A Original issue for Base version. Rev.B Document transferred to Interleaf. No changes made to the text or illustrations. 851--160116 / B...
  • Page 34 Simrad SD570 / Base version Blank page 851--160116 / B...

  • Page 35: Installation Planning

    Simrad offers free advice for installation planning. The proposal for the arrangement may be sent to Simrad for comments, or may be worked out by Simrad. If such assistance is required, the following drawings should be submitted: ·...

  • Page 36: Sonar Room Requirements

    Simrad SD570 / Base version Figure 1 - Location of the Hull Unit Sonar room requirements The sonar room should be dimensioned to house the Hull Unit and the Transceiver Unit. This because the length of the flexi- hose protected cabling from the Hull Unit to the Transceiver Unit is limited to approximately 3.5 meters.
  • Page 37 Introduction Ventilation The sonar room should preferably be connected to the ship’s ventilation system. If this is not possible, two 3- inch vent pipes must be laid from the sonar room to free air on deck. The air inlet should be close to the floor, while the outlet should be placed as high as possible.
  • Page 38 Simrad SD570 / Base version Figure 2 - Example of sonar room arrangement, seen from the bow 851--160116 / B...

  • Page 39: Installation Of The Sonar Trunk

    Introduction 2 INSTALLATION OF THE SONAR TRUNK Mounting of the trunk The location of the sonar trunk has to be carefully selected, as described in chapter 1.2. Refer also to figures 4 and 5. Note the orientation of the centre line of the trunk with regard to the mounting bolts, shown in figure 3.

  • Page 40: Protecting Blister

    Simrad SD570 / Base version Protecting blister As illustrated in figures 4 and 5, a steel blister must be fitted for protection. The blister shown in figure 4 is welded to the shell plating and then filled with oil to prevent corrosion. This method provides excellent protection and simplifies maintenance.
  • Page 41 Introduction Figure 4 - Installation of trunk with extension and oil- filled blister 851--160116 / B...
  • Page 42 Simrad SD570 / Base version Figure 5 - Installation of the trunk with open protection blister. No trunk extension. 851--160116 / B...

  • Page 43: Installation Of The Hull Unit

    Introduction 3 INSTALLATION OF THE HULL UNIT Unpacking the Hull Unit In order to prevent damage of the transducer and the transducer cables while handling the Hull Unit, these parts are especially protected. This means that both the transducer protection and the cable protection should still be mounted to the Hull Unit when it is being lowered down into the sonar room (see figure 6).

  • Page 44: Mounting The Hull Unit

    Simrad SD570 / Base version When unpacking the Hull Unit, first remove the top cover from the wooden box, then pull out the nails marked with Indian ink. Fasten the lifting device to the two lifting eye bolts on the top of the gallows and lift the Hull Unit with the protections carefully out from the transport box.

  • Page 45: Staying

    Introduction Remove the cable protection box. The transducer cables and connectors have to be kept dry and handled with care to avoid mechanical damage. Staying The Hull Unit is constructed to be in the lower position with a maximum speed of 15 knots. To prevent unwanted vibrations, the Hull Unit has to be stayed off against the bulkhead.

  • Page 46: Installation Checklist

    Simrad SD570 / Base version Installation checklist For the following check list, refer to the sonar room requirements in chapter 1.3. INSTALLATION CHECKLIST Are the access hatches satisfactory? Is the heating satisfactory? Is the insulation satisfactory? Is the ventilation satisfactory?

  • Page 47: Installation Of The Transceiver Unit

    Introduction 4 INSTALLATION OF THE TRANSCEIVER UNIT Note ! The Transceiver Unit must be mounted as a complete unit, i.e. the door should not be opened until the unit is securely fastened to the bulkhead. Before starting the mounting of the Transceiver Unit, note that the distance between the Hull Unit and the Transceiver Unit is limited because of the flexible transducer cables.
  • Page 48 Simrad SD570 / Base version Figure 8 - Mounting the brackets for the Transceiver Unit 851--160116 / B...
  • Page 49 Introduction Figure 9 - Mounting the Transceiver Unit 851--160116 / B...

  • Page 50: Installation Of The Sonar Control Unit

    Simrad SD570 / Base version 5 INSTALLATION OF THE SONAR CONTROL UNIT Location of the Sonar Control Unit The Sonar Control Unit may be mounted on a desk top, in a panel, or to the bulkhead. The necessary hardware for desk top and panel mounting of the unit is included in the delivery.

  • Page 51: Mounting Of The Sonar Control Unit

    Introduction Mounting of the Sonar Control Unit Desk top mounting Refer to figure 10 for minimum space for the desk top mounting of the cabinet. Dismount the mounting bracket from the Sonar Control Unit by unscrewing the four bolts on the front. An Allen key is located in the spare parts box.

  • Page 52: Panel Mounting

    To obtain the best operation position of the cabinet, the cabinet should be mounted with a tilt angle of approximately 20 . An optional mounting bracket can be delivered from Simrad. Dismount the mounting bracket from the Sonar Control Unit by unscrewing the four bolts on the front. An Allen key is located in the spare parts box.
  • Page 53 Introduction Bolt the bulkhead mounting bracket securely to the bulkhead. Mount the cabinet on the mounting bracket with the four bolts. 851--160116 / B...

  • Page 54: Cabling

    Simrad SD570 / Base version 6 CABLING Cable plan Figure 12 shows the cable plan for the SD 570 and SE 570 sonars. The cable numbers also refer to the interconnection diagram, drawing no. 824- 112979. This drawing is located in section Drawings in this manual.
  • Page 55 Introduction Figure 12 - Cable plan for the SD 570 / SE 570 sonars 851--160116 / B...

  • Page 56: The Sonar Control Unit Cabling

    Simrad SD570 / Base version The Sonar Control Unit cabling All the cables to the Sonar Control Unit are to be plug connected to the electronic drawer unit at the rear of the cabinet (see figure 13). The numbers on the figure refer to the cable numbers on the cable plan.
  • Page 57 Introduction Figure 13 - Cable connections to the Sonar Control Unit 851--160116 / B...

  • Page 58: The Transceiver Unit Cabling

    Simrad SD570 / Base version The Transceiver Unit cabling The cable numbers on figure 14 and in the following procedures refer to the numbers on the cable plan and the interconnection diagram. Figure 14 - The cable connection in the bottom of the Transceiver...
  • Page 59 Introduction Figure 15 - Termination of the cable main screen Continue with cable no. 4 through the cable gland on the right hand side (see figure 14) and make the termination of the main screen according to figure 15. Make the connections to terminal E201 according to the interconnection diagram.
  • Page 60 Simrad SD570 / Base version Figure 16 - The Power Supply and the HV Power Unit The mains power cable (3) may be connected to a normal mains outlet in the sonar room. If the delivered cable connector does not fit, put on a suitable connector.

  • Page 61: The Hull Unit Cabling

    Introduction The Hull Unit cabling Connection of cable no. 6 in the motor control unit: Use the cable gland on the right--hand side, and make the termination of the main screen according to figure 15. Make a slack on the cable inside the motor control unit as shown on figure 17, and make the connections to the terminal E301 according to the interconnection diagram.

  • Page 62: Connecting Auxiliary Equipment

    · Serial line, standard NMEA 0183; RS232, RS422 or Current loop. Echo sounder: In order to get a depth indication on the catch control page on the sonar, one of the following Simrad echo sounders can be connected: · EQ50, EQ55, EQ100, ES60, ES380 series, ES500 (RS232 serial line).

  • Page 63: Connecting The Course Gyro

    Introduction Connecting the course gyro The Sonar Control Unit can be connected to a course gyro with one of the following outputs (tick off for the type which will be connected): 3--phase synchro signal See chapter 7.2.1 3--phase stepper signal See chapter 7.2.2 Serial line (NMEA 0183) See chapter 7.2.3...
  • Page 64 Simrad SD570 / Base version Signal phase 1: S1- L (20- 70V) pin 2 S1- M (80- 140V) pin 9 S1- H (150- 220V) pin 1 Signal phase 2: S2- L (20- 70V) pin 11 S2- M (80- 140V) pin 3...
  • Page 65 Introduction Set the switch S101 at the rear panel on the Sonar Control Unit to OFF position. For location of the switch, refer to figure 13. Disconnect all connections to the rear panel on the Sonar Control Unit. Use the 3mm Allen key which is located in the spare parts box to unscrew the four screws on the front of the operator panel, and pull the electronic drawer carefully out.
  • Page 66 Simrad SD570 / Base version Figure 19 - The electronic drawer unit 851--160116 / B...

  • Page 67: Connecting A Course Gyro With Stepper Output

    Introduction Connecting a course gyro with stepper output First, get the specification of the gyro to fill in the following data: STEPPER DATA SPECIFICATIONS LEGAL VALUES OUTPUT VOLTAGE 20 to 220 VAC REF. POLARITY + REF. or -- REF GEAR RATIO 1:360/1:180/1:90/1:36 If it is difficult to find the specifications for the gyro, the output voltage and the reference polarity can be measured by a voltmeter...
  • Page 68 Simrad SD570 / Base version When connecting the gyro cable to the 15 pin D- connector, note that each of the three phases S1, S2, S3 has three different connection pins, marked L (Low), M (Medium) and H (High). These pins are used for different gyro output voltage values as...
  • Page 69 Introduction In order to read the data from the gyro, some DIL switches on the printed circuit board in the electronic drawer unit behind the operator panel must be selected. Use the following procedure to set the switches: Set the switch S101 at the rear panel on the Sonar Control Unit to OFF position.

  • Page 70: Connecting A Course Gyro With Serial Line Output

    Simrad SD570 / Base version Connecting a course gyro with serial line output The Sonar Control Unit can read the course gyro data (and/or the speed log data) from a serial line with on of the following outputs (tick off for the type which will be connected):...
  • Page 71 Introduction Figure 21 - Connections for a gyro with serial line output Disconnect the two display cable plugs on the drawer unit, and dismount the top cover of the drawer. Locate the DIL switch S2 (refer to figure 19), and set the switches according to the table on next page.
  • Page 72 Simrad SD570 / Base version The serial line telegram format for the course and speed data: $xxHDT,ggg.g,T<cr><1f> Heading, Degrees True $xxHDM,ggg.g,M<cr><1f> Heading, Degrees Magnetic $xxVGT,ggg.g,T,ggg.g,M,nn.n,N,kk.k,K<cr><1f> Actual track and ground speed $xxVHW,ggg.g,T,ggg.g,M,nn.n,N,kk.k,K<cr><1f> Heading and water speed xx is indicator for transmitter, for instance: ’HE’...

  • Page 73: Connecting The Speed Log

    Introduction Connecting the speed log The Sonar Control Unit can be connected to a speed log with one of the following outputs (tick off for the type which will be connected): Pulse log (100, 200 or 400 pulses per nautical mile) Serial line (RS232, RS422 or 20mA current loop) The connection of these different speed log outputs is described in the following chapters.

  • Page 74: Connecting A Speed Log With Serial Line Output

    Simrad SD570 / Base version DIL SWITCH S1 SPEED SPEED 100 pulses per nautical OFF OFF ON OFF OFF OFF OFF OFF mile 200 pulses per nautical OFF OFF OFF ON OFF OFF OFF OFF mile 400 pulses per nautical...
  • Page 75 Introduction When connecting the 9- pin D- connector, note that each of the three types of serial lines has different connection pins: RS232: Serial line signal PORT B pin- 2 Signal reference PORT B pin- 5 RS422: RS422+ PORT B pin- 1 RS422- PORT B pin- 4 20mA current loop:...

  • Page 76: Connecting Other Auxiliary Equipment

    Simrad SD570 / Base version SPEED LINK SETTING RS232 RS422 20 mA current loop Do not insert the Control drawer unit before mentioned in a later chapter. Connecting other auxiliary equipment If any other optional equipment is to be connected (echo sounder or trawl system), refer to the appendixes in this manual.
  • Page 77 Introduction Figure 25 - Mounting the electronic drawer unit 851--160116 / B...
  • Page 78 Simrad SD570 / Base version Blank page 851--160116 / B...
  • Page 79 Introduction 851- 160117 / AA000 / 3- 11 Start- up procedures This section contains the start- up procedures to be carried out after installation of the SD570/SE570 sonar. 851--160117 / B...
  • Page 80 Simrad SD570 / Base version Document revisions Date Written by Checked by Approved by Unknown 03.01.01 (The original signatures are recorded in the company’s logistic database) 851--160117 / B...
  • Page 81 Introduction Table of contents PREPARING THE START- - UP ....... . . Before start- up check list .
  • Page 82 Simrad SD570 / Base version Document history (The information on this page is for internal use) Rev.A Original issue for Base version. Rev.B Document transferred to Interleaf. No changes made to text or illustra- tions. 851--160117 / B...

  • Page 83: Preparing The Start- -Up

    Introduction 1 PREPARING THE START- -UP Before start- -up check list Before beginning with the start- up procedure, check the following: Sonar Control Unit: Check that no connections are made to the Sonar Control Unit. Transceiver Unit: Check that the ship’s mains fuses to the Transceiver Unit are disconnected.

  • Page 84: Starting Up The Stand- By Power Supply

    Simrad SD570 / Base version Starting up the stand- -by power supply In order to start up the sonar units, the 24 VDC stand- by power supply in the Transceiver Unit has to be started up first. Refer to figure 1 and use the following procedure to start up the stand- by...
  • Page 85 Introduction Figure 1 - The transceiver power system 851--160117 / B...

  • Page 86: The Hull Unit

    Simrad SD570 / Base version 2 THE HULL UNIT Starting up the Hull Unit WARNING ! Before starting up the equipment on a launched ship, make sure that there is sufficient depth for the transducer to be lowered. If starting up the equipment...
  • Page 87 Introduction Figure 2 - The motor control unit Activate the lowering contactor K302 by setting the hoisting/lowering switch S302 to LOWER position, and check if the contactor is deactivated when pressing the lower limit switch S305 downwards. Set the hoisting/lowering switch S302 to STOP position. Reinsert the three--phase mains fuses for the Hull Unit on the ship’s mains switchboard.
  • Page 88 Simrad SD570 / Base version Write measured three--phase voltage here:....... The hoist/lower motor is preconnected for 380V/440V three--phase. If the measured three--phase voltage is 230V, the motor has to be reconnected. Remove the cover for the mains connection on the motor, and refer to figure 4 to link the motor connections to correspond to the measured voltage.
  • Page 89 Introduction Figure 3 - The Hull Unit 851--160117 / B...
  • Page 90 Simrad SD570 / Base version Set the hoisting/lowering switch to HOIST for full hoisting of the transducer. The hoisting will stop automatically when the top of the transducer hits the upper limit switch S304. Repeat the hoisting/lowering to find the best position for a permanent fastening of the flexible cables.
  • Page 91 Introduction Figure 4 - Mains connection to the motor 851--160117 / B...

  • Page 92: Adjusting The Middle Position Switch

    Simrad SD570 / Base version Adjusting the middle position switch Normally, when the transducer is selected to middle position on the Sonar Control Unit, only one half of the transducer face should be outside the sonar trunk (see figure 5). The middle position...
  • Page 93 Introduction Figure 5 - Adjusting the middle position switch 851--160117 / B...

  • Page 94: The Sonar Control Unit

    Simrad SD570 / Base version 3 THE SONAR CONTROL UNIT Starting up the sonar control unit Note that the Sonar Control Unit can be connected for either 115 or 230 VAC without any special action. Both the internal power supply and the display are specified for a voltage range of minimum 85 VAC to maximum 265 VAC.
  • Page 95 - Move the menu cursor below the PP FILTER to the CONSTANTS in the extra menu, and push enter (right). - Move the cursor to SIMRAD TEST and push enter. - Move the cursor to TEST2 and push enter. - Move the cursor to SYNT. SHOAL and push enter.

  • Page 96: Checking The Control Panel

    Simrad SD570 / Base version Figure 7 - Adjustments on the display Checking the control panel The simulated trigger signal now makes it possible to operate and test most functions on the sonar control panel: Use the CURSOR JOYSTICK (1) to check if the yellow cross on the screen can be moved in any direction, and that it stops when the joystick is released.
  • Page 97 Introduction Figure 8 - The main control panel Press the GEAR button (3, button no. 4) and check if a seine circle appears beside the ship symbol, and that the button lights up. A second press should give a yellow square at the ship symbol, and a third press should remove the seine circle and extinguish the button light.
  • Page 98 Simrad SD570 / Base version Use the SEARCH SECTOR +/-- buttons (9 left) to check that the sector limits can be adjusted from 22° to 360°. Press the POSITION TRACK button (9) and check that a circle appears at the yellow cross position.

  • Page 99: Checking The Hoisting/Lowering System

    Introduction 4 CHECKING THE HOISTING/LOWERING SYSTEM During the following procedure, there must be one person on the bridge, and one in the sonar room to control if the hoisting/lowering system works properly. If problems occur in the sonar room, press the button marked ”0” on the motor overload switch S301 (see figure 2) to stop the hoisting/lowering.
  • Page 100 Simrad SD570 / Base version Press the HOIST button, and check if the text HOISTING: UPPER is shown in the menu. Also check that both buttons light during the hoisting, and that only the HOIST button lights when the transducer stops in the fully hoisted position.

  • Page 101: Checking The Sonar Room Functions

    Introduction Checking the sonar room functions Note that this checklist has to be coordinated with chapter 4.1. Check that the depth is sufficient for lowering of the transducer. Start up the Sonar Control Unit and check that the green ON/OFF--HOIST button lights and that the upper line in the menu shows the text TRANSD.
  • Page 102 Simrad SD570 / Base version Press the HOIST button for approximately 2 seconds, and check if the text HOISTING: UPPER is shown in the menu. Also check that both buttons light during the hoisting, and that only the HOIST button lights when the transducer stops in the fully hoisted position.

  • Page 103: The Transceiver Unit

    Introduction 5 THE TRANSCEIVER UNIT Starting up the Transceiver Unit Remove the fuses F204 and F205 on the HV power unit (refer to figure 1). Start up the Transceiver Unit by setting the service switch S202 on the power supply to SERVICE position (refer to figure 1).

  • Page 104: Self- Noise Test

    Simrad SD570 / Base version Self- -noise test In order to make a self- noise test of the sonar installation, start up the sonar and make the following settings in the menu: GAIN..: MODE..: BOW UP TX POWER...: PING SECTOR: OMNI TVG..:...

  • Page 105: Connecting The Transducer

    Introduction Connecting the transducer Note ! The transducer cables and connectors have to be kept dry and handled with care to avoid mechanical damage. In order to make sure that nobody is starting up the system, pull out the mains connector P201 on the power supply in the Transceiver Unit.
  • Page 106 Simrad SD570 / Base version Fasten the cable gland and put the slack of the cables into the bottom of the Transceiver Unit as shown on figure 10. Continue with the other flexible cable in the same way. Figure 10 - Threading of the transducer cables Remount the inner cable strapping bar and fasten connector no.
  • Page 107 Introduction Continue to connect the lower connector row with numbers referred to figure 11. Remember to fasten the cables to the strapping bar. Figure 11 - Connecting the transducer cable Remount the outer strapping bar and fasten the connectors to the upper front connectors on the TRBs as shown on figure 11.

  • Page 108: System Start- -Up

    Simrad SD570 / Base version 6 SYSTEM START- -UP Note ! To do the final test, the vessel must be in the sea. This because the transducer always must be in water before starting the transmitting. Air- -bleeding of the sonar trunk...

  • Page 109: Starting Up The Transmitter

    - Move the menu cursor below PP FILTER to CONSTANTS in the extra menu, and push enter. - Move the cursor to SIMRAD TEST and push enter. - Move the cursor to TX POWER and push enter. - Move the cursor to ON and push enter.
  • Page 110 Simrad SD570 / Base version Check that the voltmeter on the HV power unit shows approx. 40 volt. Set the TX POWER in the main menu to FULL, and check that the echoes become still stronger. Check that the voltmeter on the HV power unit shows approx.

  • Page 111: Actions On The Transceiver Unit

    - Move the menu cursor below the PP filter to the CONSTANTS in the extra menu, and push enter. - Move the cursor to SIMRAD TEST and push enter. 851--160117 / B...
  • Page 112 Simrad SD570 / Base version - Move the cursor to TX POWER and push enter. - Move the cursor to ON and push enter. In such a case, the sonar trunk must always be air- bleeded. Check that the voltmeter on the HV power unit shows approx.

  • Page 113: Alignment Of The Sonar Picture

    Introduction Alignment of the sonar picture If the Hull Unit is installed differently from the recommended orientation shown in figure 6 in the section “Installation procedures”, carry out the following procedure to align the sonar echo picture on the display: Estimate the approximate angle (0°...

  • Page 114: Testing The Auxiliary Equipment

    Simrad SD570 / Base version 7 TESTING THE AUXILIARY EQUIPMENT General If the connection of the auxiliary equipment is not finished, go back to chapter 7 in section “Installation procedures” to make the connections and the switch/link settings for the auxiliary equipment in question.
  • Page 115 Introduction If the direction is wrong, change two of the gyro phases for the Sonar Control Unit in the gyro connection unit. If the gear ratio is wrong, check the table for the gyro switch setting in chapter 7.2 in section “Installation procedures”.

  • Page 116: Checking The Speed Log Readout

    Simrad SD570 / Base version Checking the speed log readout If the speed log is equipped with a test output signal, this test can be carried out with the ship ashore, but if not, this test must be done while the ship is sailing.

  • Page 117: Remounting The Electronic Drawer Unit

    Introduction Remounting the electronic drawer unit When both the course gyro and speed log work properly, the electronic drawer unit can be installed into the cabinet: Set the switch S101 at the rear of the drawer to OFF. If the external cable connections not are threaded through the cabinet, disconnect all the connections at the rear of the drawer unit.
  • Page 118 Simrad SD570 / Base version If the external cable connections are disconnected, reconnect all the external cables at the rear of the drawer unit. Set the switch S101 at the rear of the drawer unit to ON. Start up the Sonar Control Unit, and check that the picture is coming up on the display.

  • Page 119: Final Tests And Measurements

    Introduction 8 FINAL TESTS AND MEASUREMENTS General In order to verify that the sonar works properly, the following measurements and tests must be carried out: - Source Level (SL) measurements - Receiving voltage response (VR) - Noise/speed curve To make these tests and measurements, an oscilloscope, a signal generator and a test hydrophone must be available.
  • Page 120 Simrad SD570 / Base version Figure 14 - Source Level (SL) measurements 851--160117 / B...
  • Page 121 14. Note that an optional cable with connectors for the TX ENABLE pulse can be ordered from Simrad. As indicated in the figure, the distance between the transducer and the hydrophone should be approximately 5 - 10 meters.
  • Page 122 Simrad SD570 / Base version Use a weight to keep the hydrophone in a stable vertical position. Lower the hydrophone and adjust the it to get maximum voltage on the oscilloscope at a tilt angle of 0°. Measure the time delay from the negative going TX ENABLE pulse to the transmitter pulse on the oscilloscope as shown in figure 14.
  • Page 123 Introduction Make the requisite calculations in table 2, and enter the results of the 20 log r and the U Hydr. into table 3. Also fill in the M total from table 1 into table 3. SL = U Hydr -- M + 20 log r U Hydrophone dB//1V --9.9...

  • Page 124: Receiving Voltage Response (Vr)

    Simrad SD570 / Base version Receiving voltage response (VR) In order to measure the receiving voltage response, use the test hydrophone in the same position as for the source level measurements. Use the following menu settings: RANGE..: 3500 M GAIN..: MODE..:...
  • Page 125 Introduction Measurements/calculations Value Unit Example Noise level --25.2 Hydrophone U(p--p) volt 0.27 voltage voltage U(RMS) = U(p--p)/2Ö2 volt 0.095 U Hydr = 20 log U(RMS) dB//1V --20.4 Table 4 Measurement and calculation results Make the requisite calculations in table 4 and enter the result into table 5.

  • Page 126: Noise/Speed Curve

    Simrad SD570 / Base version Noise/speed curve To make a noise/speed curve of the ship, make the following settings in the menu: RANGE..: 3500 M GAIN..: MODE..: BOW UP TRANSMIT...: MONO PULSEFORM..: CW-NORM TX POWER...: PINGSECTOR.: OMNI TVG..: AGC..: RCG..: PP-FILTER..:...
  • Page 127 Introduction SPEED BEARING (KNOTS (KNOTS - -120° - -60° 0° +60° +120° +180° Table 7 Noise measurements When the measurements are finished, make a plot of the noise for 0° bearing into table 9. The noise level at full speed should preferably not exceed the 0 dB line.
  • Page 128 Simrad SD570 / Base version In order to find out if a high noise is caused by flow noise of the ship’s hull engine/propeller, make acceleration/retardation test as described below. First, enter the noise level for 0° bearing from table 7 into the column for STABLE SPEED in table 8.
  • Page 129 Introduction NOISE/SPEED CURVE FOR 0° BEARING WITH MAXIMUM GAIN MAXIMUM GAIN _________STABLE SPEED ---------ACCELERATION ..RETARDATION ..RETARDATION KNOTS 851--160117 / B...

  • Page 130: Installation Remarks And Signature

    Simrad SD570 / Base version 9 INSTALLATION REMARKS AND SIGNATURE Installation remarks Installation signature: ________________________________ ________________________________ Place Date Signature 851--160117 / B...
  • Page 131 Introduction 851- 160503 / AA000 / 3- 11 Trunk systems This document describes the different trunk systems that can be used with the SD 570/SE 570 Hull Unit. Also described are the adapter flanges which must be used if the Hull Unit is to be installed into already installed SQ4, SQ, SB2 and SK3 trunks 851--160503 / B...
  • Page 132 Simrad SD570 / Base version Document revisions Date Written by Checked by Approved by Unknown 03.01.01 (The original signatures are recorded in the company’s logistic database) 851--160503 / B...
  • Page 133 Introduction Table of contents INTRODUCTION ..........DIFFERENT TRUNK SYSTEMS .
  • Page 134 Simrad SD570 / Base version Document history (The information on this page is for internal use) Rev.A Original issue for Base version. Rev.B Document transferred to Interleaf. No changes made to text or illustra- tions. 851--160503 / B...

  • Page 135: Introduction

    SL trunks, but for the SQ4, SQ, SB2 and SK3 trunks, an adapter flange has to be mounted. These adapter flanges can be delivered as an option from Simrad. In such a case, refer to chapter 2 to find which type of adapter flange that fits to the already installed trunk.

  • Page 136: Different Trunk Systems

    Simrad SD570 / Base version 2 DIFFERENT TRUNK SYSTEMS The figures in the following chapters show the top flange for the different trunks which can be used for installing the SD 570 / SE 570 Hull Unit. If a trunk is already installed, use these figures to find the type of trunk.

  • Page 137: The Sq4 Trunk

    Introduction The SQ4 trunk Figure 2 shows the top flange for the SQ4 trunk. Figure 2 - The top flange for the SQ4 trunk The SQ4 trunk must have an adapter flange mounted (refer to figure 5) for installation of the SD 570 / SE 570 Hull Unit. Figure 5 also shows the minimum height of the trunk.

  • Page 138: The Sq And Sb2 Trunk

    Simrad SD570 / Base version The SQ and SB2 trunk Figure 3 shows the top flange for the SQ and SB2 trunk. Figure 3 - The top flange for the SQ and SB2 trunks The SQ and SB2 trunks must have an adapter flange mounted (refer to figure 6) for installation of the SD 570 / SE 570 Hull Unit.

  • Page 139: The Sk3 Trunk

    Introduction The SK3 trunk Figure 4 shows the top flange for the SK3 trunk. Figure 4 - The top flange for the SK3 trunk The SK3 trunk must have an adapter flange mounted (refer to figure 7) for installation of the SD 570/SE 570 Hull Unit. Figure 7 also shows the minimum height of the trunk.

  • Page 140: Adapter Flanges

    Figure 5 shows the SQ4 trunk with the adapter flange for mounting the SD 570 / SE 570 Hull Unit. This adapter flange may be made by the shipyard, or be delivered from Simrad as an option (Simrad reg. no. SD5- 112641). The optional adapter flange which is approved by Det Norske Veritas (DnV), also includes a blind cover and a gasket set.
  • Page 141 Introduction Figure 5 - The SQ4 trunk with adapter flange 851--160503 / B...

  • Page 142: Sq And Sb2 Adapter Flange

    Figure 6 shows the SQ and SB2 trunk with the adapter flange for mounting the SD 570 / SE 570 Hull Unit. This adapter flange may be made by the shipyard, or be delivered from Simrad as an option (Simrad reg. no. SD5- 112642). The optional adapter flange which is approved by Det Norske Veritas (DnV), also includes a blind cover and a gasket set.
  • Page 143 Introduction Figure 6 - The SQ and SB2 trunks with adapter flange 851--160503 / B...

  • Page 144: Sk3 Adapter Flange

    Figure 7 shows the SK3 trunk with the adapter flange for mounting the SD 570 / SE 570 Hull Unit. This adapter flange may be made by the shipyard, or be delivered from Simrad as an option (Simrad reg. no. SD5- 112643). The optional adapter flange which is approved by Det Norske Veritas (DnV), also includes a blind cover and a gasket set.
  • Page 145 Introduction Figure 7 - The SK3 trunk with adapter flange 851--160503 / B...

  • Page 146: Mounting The Adapter Flange

    Simrad SD570 / Base version 4 MOUNTING THE ADAPTER FLANGE If the adapter flange is delivered from Simrad, the gasket to be used between the old trunk and the adapter flange is located in a plastic bag under the blind cover.
  • Page 147 Introduction Blank page 851--160503 / B...
  • Page 148 Simrad SD570 / Base version Blank page 851--160503 / B...

  • Page 149: Drawing File

    Introduction 851- 160118 / AA000 / 3- 11 Drawing file This section contains the drawings required for the system installation. 851--160118 / B...
  • Page 150 Simrad SD570 / Base version Document revisions Date Written by Checked by Approved by Unknown 03.01.01 (The original signatures are recorded in the company’s logistic database) 851--160118 / B...
  • Page 151 ....... 830- 113235 (838- 72) Adapter flange SQ and SB2 for SD570 ......
  • Page 152 Simrad SD570 / Base version Document history (The information on this page is for internal use) Rev.A Original issue for Base version. Rev.B Document transferred to Interleaf. No changes made to text or illustra- tions. 851--160118 / B...
  • Page 165 Appendices 851- 160675 / AA000 / 4- 11 Appendices This section provides information for installation of optional equipment to the sonar. 851--160675 / B...
  • Page 166 Simrad Document revisions Date Written by Checked by Approved by 22.01.99 SØJ SØJ 08.01.01 (The original signatures are recorded in the company’s logistic database) 851--160675 / B...
  • Page 167 Appendices Table of contents Installation of the Stabilization kit 851- 160538 Connecting an external loudspeaker 851- 160668 Connecting the EQ 50 Echo sounder 851- 160666 Connecting the EQ 55 Echo sounder 851- 160669 Connecting the EQ 100 Echo sounder 851- 160504 Connecting the ES60 Echo sounder 851- 164094 Connecting the ES 380 series Echo sounder...
  • Page 168 Simrad Document history (The information on this page is for internal use) Rev.A Original issue. Rev.B Installation information on ES60 added. 851--160675 / B...
  • Page 251 &RQQHFWLQJ WKH ,7, 7UDZO LQVWUXPHQWDWLRQ V\VWHP   $$   &RQQHFWLQJ WKH 6LPUDG ,7, 7UDZO ,QVWUXPHQWDWLRQ 6\VWHP     $...
  • Page 252 6LPUDG 6RQDU &RQWURO 8QLW 'RFXPHQW UHYLVLRQV 'DWH :ULWWHQ E\ &KHFNHG E\ $SSURYHG E\  &/ 6‘- 6‘- & 7KH RULJLQDO VLJQDWXUHV DUH UHFRUGHG LQ WKH FRPSDQ\·V ORJLVWLF GDWDEDVH     $...
  • Page 253 &RQQHFWLQJ WKH ,7, 7UDZO LQVWUXPHQWDWLRQ V\VWHP &RQWHQWV ,1752'8&7,21                                              &20081,&$7,21 6(/(&7,21                                &$%/,1*...
  • Page 254 6LPUDG 6RQDU &RQWURO 8QLW 'RFXPHQW KLVWRU\ 7KH LQIRUPDWLRQ RQ WKLV SDJH LV IRU LQWHUQDO XVH 5HY $ 2ULJLQDO LVVXH     $...
  • Page 255 &RQQHFWLQJ WKH ,7, 7UDZO LQVWUXPHQWDWLRQ V\VWHP  ,1752'8&7,21 :KHQ WKH ,7, WUDZO V\VWHP LV FRQQHFWHG WR WKH 6RQDU &RQWURO 8QLW WKH LQIRUPDWLRQ H[FKDQJHG EHWZHHQ WKH ,7, DQG WKH VRQDU LV ,7, WR 6RQDU 7UDZO SRVLWLRQ UHODWLYH WR YHVVHO 'HSWK RI WUDZO EHORZ VXUIDFH 7UDZO KHDGURSH WR IRRWURSH DQG ERWWRP 7UDZO GRRU VSUHDG 7UDZO ILOOLQJ...
  • Page 256 6LPUDG 6RQDU &RQWURO 8QLW  &20081,&$7,21 6(/(&7,21 :KHQ WKH 6RQDU &RQWURO 8QLW LV GHOLYHUHG IURP 6LPUDG WKH WUDZO V\VWHP FRPPXQLFDWLRQ LV VHOHFWHG WR 56 7KH IROORZLQJ SURFHGXUH LV RQO\ UHTXLUHG LI DQ )6  ZLWK  P$ FXUUHQW ORRS KDV EHHQ FRQQHFWHG WR WKH VRQDU ,I QRW FRQWLQXH WR FKDSWHU  &DEOLQJ ,I WKH HOHFWURQLF GUDZHU XQLW LV PRXQWHG LQ WKH 6RQDU &RQWURO 8QLW XVH WKH IROORZLQJ SURFHGXUH IRU GLVPRXQWLQJ WKH GUDZHU...
  • Page 257 &RQQHFWLQJ WKH ,7, 7UDZO LQVWUXPHQWDWLRQ V\VWHP œ 3XVK WKH HOHFWURQLF GUDZHU FDUHIXOO\ RXW  GR QRW SXOO RQ WKH MR\VWLFNV %H DZDUH RI WKH WZR FDEOHV WR WKH GLVSOD\ RQ WKH WRS RI WKH GUDZHU XQLW œ 'LVFRQQHFW WKH WZR GLVSOD\ FDEOH SOXJV RQ WKH GUDZHU XQLW œ...
  • Page 258 6LPUDG 6RQDU &RQWURO 8QLW œ 5HIHU WR ILJXUH  WR UHFRQQHFW WKH WZR GLVSOD\ FDEOHV œ $UUDQJH WKH WZR GLVSOD\ FDEOHV DV VKRZQ LQ ILJXUH  DQG JXLGH WKH GUDZHU XQLW JHQWO\ LQWR WKH FDELQHW (QVXUH WKH WZR JXLGLQJ SLQV DW WKH UHDU RI WKH FDELQHW PDWFK WKH WZR KROHV DW WKH UHDU RI WKH GUDZHU XQLW )DVWHQ WKH GUDZHU XQLW ZLWK WKH IRXU IURQW IDVWHQLQJ VFUHZV )LJXUH   )LJXUH  0RXQWLQJ WKH HOHFWURQLF GUDZHU XQLW...
  • Page 259 &RQQHFWLQJ WKH ,7, 7UDZO LQVWUXPHQWDWLRQ V\VWHP  &$%/,1* 7KH IROORZLQJ SDUWV DUH XVHG IRU WKH FDEOLQJ &DEOH 7KUHH [ PP ZLUHV ZLWK VKLHOG ,7, SOXJ 6WDQGDUG '7(  SLQ PDOH FRQQHFWRU 7KH FRQQHFWRU FDQ EH GHOLYHUHG E\ 6LPUDG   SLQ ' FRQQHFWRU UHJ QR    &RQQHFWRU KRXVLQJ UHJ QR   6RQDU SOXJ 6WDQGDUG '7(  SLQ PDOH FRQQHFWRU...
  • Page 260 6LPUDG 6RQDU &RQWURO 8QLW  ),1$/ 7(67 7R JHW DFFHVV WR WKH WHVW PHQX RQ WKH ,7, SUHVV WKH PHQX MR\VWLFN WR WKH OHIW DQG NHHS LW LQ WKDW SRVLWLRQ GXULQJ WKH VWDUW XS 7KHQ PDNH WKH IROORZLQJ VHWXS LQ WKH PHQX WR JHW WKH VLPXODWHG GDWD RXWSXW $&7,9( 6(16256 @ $// 6(16256 72   &$7&+ $9$,/ 72   ...
  • Page 270 E 2004 Simrad AS ISBN 82-8066-018-6 Simrad AS Strandpromenaden 50 Box 111 N-3191 Horten Telephone: +47 33 03 40 00 Facsimile: +47 33 04 29 87 M A X I M I Z I N G Y O U R...

Table of Contents
