Installation manual
Simrad SP90
Low frequency long range fish finding sonar
www.simrad.com
T E C H N O L O G Y F O R S U S T A I N A B L E F I S H E R I E S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP90 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Simrad SP90

  • Page 1 Installation manual Simrad SP90 Low frequency long range fish finding sonar www.simrad.com T E C H N O L O G Y F O R S U S T A I N A B L E F I S H E R I E S...
  • Page 3 851-164510 / Rev.E Simrad SP90 Low frequency long range fishery sonar Installation manual WARNING The sonar must never be powered up when the ship is in dry dock. The transducer will be damaged if it transmits in open air. To prevent inadvertent use of the sonar, pull out the mains plug on the Sonar Processor Unit whenever the vessel is in dry dock.
  • Page 4 Simrad AS. The information contained in this document is subject to change without prior notice. Simrad AS shall not be liable for errors contained herein, or for incidental or consequential damages in connection with the furnishing, performance, or use of this document.
  • Page 5: Installation Planning

    Installation manual Sections Introduction This section provides a generalk introduction to the sonar installation. Refer to page 1. Installation planning This section explains how the installation is planned, and which parameters need considering. Refer to page 24. Installation of the Sonar Trunk This section explains how to manufacture and install the sonar trunk.
  • Page 6: Drawing File

    Simrad SP90 Technical specifications Refer to page 163. Drawing file Refer to page 186. Installation remarks and signature Refer to page 213. 851-164510 / Rev.E...
  • Page 7: Table Of Contents

    Installation manual INTRODUCTION ......... The purpose of this manual .
  • Page 8 ......... . . SP90 Cable plan .
  • Page 9 Installation manual 10 TESTING THE PERIPHERAL EQUIPMENT ....10.1 Introduction ..........10.2 Interface settings .
  • Page 10 Simrad SP90 High voltage safety warning Precautionary measures Check if the victim is breathing. If not, check if his heart is beating. The pulse is The voltages used to power this equipment are normally easily found in the main arteries potentially lethal.
  • Page 11 Installation manual Artificial respiration If started quickly and performed correctly, the resuscitation methods described will keep a Kneel besides the victim’s head. Place one sufficient volume of oxygenated blood flowing hand under his neck and lift, allowing his trough the victims body to allow full recovery. head to fall back.
  • Page 12 Simrad SP90 VIII 851-164510 / Rev.E...
  • Page 13: Introduction

    The purpose of this manual The purpose of this manual is to provide the information and basic drawings required for installation of the Simrad SP90 sonar system. These instructions must be followed carefully to ensure optimal sonar performance. As a guide, installation procedures are presented in the order they are to be performed.
  • Page 14: System Diagram

    Simrad SP90 System diagram A simplified SP90 system diagram is shown. (A) = Colour display (B) = Operating Panel (C) = Sonar Processor Unit (D) = Sonar Interface Unit (E) = Loudspeaker (F) = Multiple interface lines to peripheral equipment...
  • Page 15 Introduction 115/230 Vac 115/230 Vac Wheelhouse Sonar room 115/230 Vac 230/380/440 Vac 3-phase 851-164510 / Rev.E...
  • Page 16: Scope Of Supply

    Simrad SP90 Scope of supply Main units The standard Simrad SP90 sonar system is comprised of the following main units: Unit Order number Operating Panel SH8--203593 Sonar Processor Unit SP9--207895 Sonar Interface Unit SP7--207891 Transceiver Unit SP9--204930 SP92 Hull Unit, 1.2 m...
  • Page 17 24 knots. The mounting flange has 24 bolts with pitch centre diameter (PCD) 680 mm. The following options are available: • 1.2 and 1.6 meter hull units (SP90 and SP91) are available for mounting on a trunk with 20 bolts and 620 mm pitch centre diameter.
  • Page 18 0183 serial line, a gyro interface box is required. Unit Order number LR40 Gyro interface unit 298--078535 Frequency The SP90 can be configured to operate on triple or multiple frequencies. This feature is especially helpful in suppressing interference from other sonars. Unit Order number Triple frequencies...
  • Page 19: Peripheral Equipment

    Introduction Peripheral equipment Required inputs The Simrad SP90 sonar system requires input from both a speed log and a course gyro. Inaccurate data from either of these instruments will result in an incorrect indication of vessel and target movement. Speed log The speed log parameters are: •...
  • Page 20: Radio Buoy System

    • RS-232 Serial line, standard NMEA 0183 Catch monitoring system To provide trawl and purse seine depth information on the sonar’s display, the following Simrad catch monitoring systems may be connected: • Simrad PI30 Catch monitoring system (RS-232) • Simrad PI32 Catch monitoring system (RS-232) Trawl system To provide trawl information on the sonar’s display, one of the...
  • Page 21: Supply Conditions

    (normally the owner of the vessel which the equipment has been installed). The Simrad SP90 system guarantee period (as specified in the contract) begins when the acceptance documents have been signed unless other arrangements have been made in the contract.
  • Page 22: General Safety Rules

    Simrad SP90 General safety rules The SP90 sonar system operates on 230 Vac, 50/60 Hz. Warning: This voltage can be lethal. The following safety precautions must be followed at all times during installation and maintenance work: Always switch off all power before installation or maintenance.
  • Page 23: General Installation Requirements

    Introduction General installation requirements Responsibility and approval The Simrad SP90’s Hull Unit sleeve has been approved by Det Norske Veritas (DNV) Classification society. Individual Hull Unit installations must be approved on a case-by-case basis with regard to the vessel’s national registry and corresponding maritime authority.
  • Page 24 Simrad SP90 Dry docking Make sure that ample clearance under the sonar trunk and/or protection blister is provided when dry docking the vessel. Avoid locating supporting blocks or structures in the vicinity of this equipment. Note: The location of the sonar trunk and/or protection blister must be noted on the vessel’s docking plan for future reference.
  • Page 25: Equipment Handling

    Unless otherwise stated in the accompanying documentation, electronic, electro-mechanical and mechanical units supplied by Simrad can be transported using all methods approved for delicate equipment; (by road, rail, air or sea). The units are to be transported in accordance with general or specific instructions for the appropriate unit(s), using pallets, transport cases, or carton boxes as appropriate.
  • Page 26 Simrad SP90 Lifting A heavy crate will normally be marked with its weight, and the weights of other cartons or crates will normally be entered on the packing list. • Always check the weight of a crate before attempting to lift •...
  • Page 27 Introduction The crates must not be placed on top of each other, unless specific markings permit this. The crates must not be placed directly on a dirt-floor. Do not open the crate for inspection unless special circumstances permit so. - “Special circumstances” may be suspected damage to the crate and its content, or inspections by civil authorities.
  • Page 28 Describe the damage and collect photographic evidence if possible. Send the inspection report to Simrad as soon as possible. • If the units are not damaged, check the humidity absorbing material. If required, dry or replace the bags, then repack the unit(s) according to the packing instructions.
  • Page 29 Introduction • Check the carton before opening it to ensure it shows no signs of dropping, immersion in water or other mishandling. - If the carton shows signs of such damage, refer to the paragraph covering Inspection on receipt. • Place the carton on a stable work bench or on the floor with the top of the carton uppermost.
  • Page 30 Simrad SP90 Note: Cables must never be used as carrying handles or lifting points. Note: Do not break the seal to open a circuit board package before the board is to be used. If the board package is returned to the...
  • Page 31 Introduction Storage Pre-installation storage The equipment should be stored in its original transportation crate until ready for installation. The crate must not be used for any purpose for which it was not intended (eg. work platform etc.). Once unpacked, the equipment must be kept in a dry, non condensing atmosphere, free from corrosive agents and isolated from sources of vibration.
  • Page 32 Simrad SP90 • Wipe the cabinet externally using a damp cloth and a little detergent. Do not use excessive amounts of water as the unit may not be water tight. On completion, dry the unit thoroughly. • All surfaces must be inspected for signs of corrosion, eg.
  • Page 33 Cables Wipe clean all exposed cables, and check for damage. If a cable shows signs of wear or ageing, contact Simrad for advice. Internal batteries If the unit contains batteries, these may discharge slowly during storage.
  • Page 34 Simrad SP90 • Large units must be placed in a suitable cardboard box or wooden crate. The unit must be protected against physical damage by means of shock-absorbing insulation mats. The box must be clearly marked with its contents, and must be stored in a dry and dust-free area.
  • Page 35 Introduction Caution: If, for any reason, it is necessary to move the circuit board or components from the conductive service mat, they must be placed in an approved anti-static transportation container (e.g. static shielding bag) before transportation. • During installation and servicing, all electrical equipment (soldering irons, test equipment etc.) must be earthed.
  • Page 36: Installation Planning

    This chapter provides the marine engineers responsible the information necessary to plan and install the sonar’s Hull Unit according to Simrad’s requirements. Correct installation of the sonar transducer is vital to the system’s performance. Several variables must be taken into consideration, the most important of which is the vessel’s construction.
  • Page 37: Location Of The Hull Unit

    The Hull Unit should preferably be located within 1/10 to 1/3 the vessel’s Length Between Perpendiculars (LBP) measured from its Forward Perpendicular (FP). Deviations from this rule should not be made without consulting Simrad. Athwartships The Hull Unit may be located on the Centre Line (CL) of the vessel, or alongside its keel.
  • Page 38 Simrad SP90 Important considerations The Hull Unit trunk must be installed so that it will be vertical under normal operating conditions. The primary sources of underwater disturbance (other than a vessel’s main propeller and bow/sternthruster) that affect transducer reception are: •...
  • Page 39: Sonar Room Requirements

    Installation planning Sonar room requirements Size The sonar room must be dimensioned to house both the Hull Unit and the Transceiver Unit. This is due to the limited length of the flexible hose protected cabling (approximately 3.5 m) connecting these two units. A well designed sonar room reduces the risk of corrosion and simplifies maintenance increasing system reliability.
  • Page 40 Simrad SP90 On the main deck, the best ventilation is provided when the outlet pipe is at least four meters higher than the inlet pipe. To keep out sea water, rain and spray, the ventilation pipes should be fitted with goosenecks of the equivalent.
  • Page 41 Installation planning Load capacity minimum 2 tonnes Minimum 4000 mm 3000 (recommended + lifting device) Air bleeding pipe Air vent pipes (Min. diameter 10 mm) (Min. diameter 50 mm) Lighting Transceiver Unit Heater Pipes (10 mm) All measurements in mm Figure 1 Sonar room example 851-164510 / Rev.E...
  • Page 42 Simrad SP90 1600 (*) 650 (*) Ladder 500 (*) Hatch (min. 680 x 1000) Removable support brackets 1600 (*) 150 (*) Transducer cable Transceiver Unit (Total length 4 m) All measurements in mm (*) = recommended minimum Figure 2 Sonar room example - top view...
  • Page 43: Sonar Trunk

    A DnV approved trunk with a blind cover can be ordered from Simrad as an optional delivery, or it may be manufactured by the installation shipyard based on the drawings in this manual and the properties of the hull.
  • Page 44: Mounting The Trunk

    Simrad SP90 Mounting the trunk The location of the sonar trunk must be carefully selected. Note: Note the orientation of the centre line of the trunk with regard to the mounting bolts. Note: Remove the gasket on the top flange during welding.
  • Page 45: Protection

    Sonar trunk Protection Protecting blister A steel blister must be fitted for protection. The blister shown is welded to the shell plating and then filled with oil to prevent corrosion. This method provides excellent protection and simplifies maintenance. Corrosion protection As soon as all installation, welding and grinding has been performed, the trunk and the surrounding area should be primed and painted using a quality protective coating.
  • Page 46: Principles

    Simrad SP90 Principles The drawings on the next pages illustrate the installation of the sonar trunk. 851-164510 / Rev.E...
  • Page 47 Sonar trunk A: As short as possible B: Max. 47 1/4" (1200 mm) C: Min. 1 9/16" (40 mm) D: Min. 35 7/8" (910 mm) Fore-and-aft view E: Min. 24" (610 mm) 3-4 knee-plates, must be welded to frames or floors Bottom view Thickness of plates: Knee-plates 3/8"...
  • Page 48 Simrad SP90 A: As short as possible B: Max. 47 1/4" (1200 mm) C: Min. 1 9/16" (40 mm) D: Min. 35 7/8" (910 mm) Fore-and-aft view E: Min. 24" (610 mm) 3-4 knee-plates, must be welded to frames or floors...
  • Page 49: Trunk Installation Measurements

    Sonar trunk Trunk installation measurements For future reference, the measurements “A”, “B”, “C” and “D” from the drawing must be made and noted in the Trunk installation measurements table provided below. Millimetres Inches “A” “B” “C” “D” Table 1 Trunk installation measurements If an other type of installation is chosen, make a sketch including all relevant dimensions.
  • Page 50: Hull Unit

    Simrad SP90 4 HULL UNIT Introduction The hull unit is a crucial part of the sonar system. Due to its physical size and weight, and the fact that the trunk penetrates the vessel hull, it is very important that the hull unit is installed and secured properly.
  • Page 51: Hull Unit Models

    Hull unit Hull unit models The SP90 sonar may be delivered with one out of four different hull unit models. • SP90 - This hull unit has 1.2 m stroke length, and it is designed for maximum speed 25 knots. It will...
  • Page 52: Unpacking

    Simrad SP90 Unpacking Warning: Do not remove the transducer protection from the transducer until just before the Hull Unit is to be lowered onto the trunk. The transducer is specially protected to prevent damage during transport and installation of the Hull Unit, and should remain attached while it is being manoeuvred into the sonar room.
  • Page 53: Mounting

    Hull unit Mounting The Hull Unit should normally be oriented with the hoisting/lowering motor pointing aft. If this orientation makes the Motor Control Unit attached to the Hull Unit difficult to access, the Hull Unit may be oriented in the most suitable position.
  • Page 54: Bleeding Air

    Simrad SP90 Bleeding air To avoid damage to the transducer by the transmission in air inside the trunk, a pipe with a minimum inside diameter of 10 mm must be attached to the air bleeding cock. This vent should be run with continuous rise to the main deck or through the vessel’s side.
  • Page 55: Mechanical Support

    Hull unit Mechanical support To ensure the safety of the sonar system and the vessel, it is very important that the mechanical support of the hull unit gantry is satisfactory. To prevent unwanted vortex induced vibration, the Hull Unit must be secured to the bulkhead. Use the two pre-drilled holes on the gantry to mount support brackets in the fore-and-aft and sideways direction.
  • Page 56: Transducer Alignment

    Simrad SP90 Transducer alignment Note that the transducer should not be mechanically aligned even though the Hull Unit is oriented differently than shown. Transducer alignment will be later performed in the Processor Unit by rotating the echo presentation in the Processor Unit.
  • Page 57: Installation Check-List

    Hull unit Installation check-list Refer to section Sonar room requirements when you fill in the following check list. INSTALLATION CHECK- -LIST Are the access hatches satisfactory? Is the heating satisfactory? Is the insulation satisfactory? Is the ventilation satisfactory? Is the air vent pipe satisfactory? Is a bilge pump installed? Is the lighting satisfactory? Is the sonar room suitably decked?
  • Page 58: Transceiver Unit

    Simrad SP90 5 TRANSCEIVER UNIT Introduction Note: The Transceiver Unit must be mounted as a complete unit. The door must not be opened until the unit is securely fastened to the bulkhead. Before mounting the Transceiver Unit, observe that the distance between the Hull Unit and the Transceiver Unit is restricted by the flexible transducer cable joining the two.
  • Page 59: Installation Procedure

    Transceiver unit Installation procedure Observe the following procedure. To ensure correct operation, tick off every item when the action has been carried out. Remove the two mounting brackets which are fastened to the shock absorbers on the Transceiver Unit. - Use the Allen key found in the plastic bag fastened to the upper shock absorber.
  • Page 60: Transceiver Unit Drawings

    The drawings required to install the Transceiver Unit are provided. Overhead Angle bars with threaded holes for shock absorbers. Bulkhead Bars supplied by Simrad. Figure 8 Mounting the Deck brackets for the Transceiver Unit - side view 851-164510 / Rev.E...
  • Page 61 Transceiver unit ±10 Min. Min. App. 40 App. 70 (CD1988A) Figure 9 Mounting the brackets for the Transceiver Unit - forward view 851-164510 / Rev.E...
  • Page 62 Simrad SP90 Figure 10 Mounting the Transceiver Unit 851-164510 / Rev.E...
  • Page 63: Wheelhouse Units

    Wheelhouse units 6 WHEELHOUSE UNITS Introduction This chapter explains how to install the SP90 hardware units normally positioned in the wheelhouse. Topics → Location, page 52 → Colour display, page 55 → Operating Panel, page 56. → Sonar Processor Unit, page 57 →...
  • Page 64: Location

    Simrad SP90 Location On board routines should be thoroughly discussed with the captain when selecting the locations for the Operating Panel and display. Distances Observe the maximum distances between the wheelhouse units. 2.5 m 115/230 Vac 2.5 m 115/230 Vac 4.5 m...
  • Page 65: Sonar Interface Unit

    Wheelhouse units Display unit The display unit should be located so that it is best protected from glare which reduces readability. It may be: • Panel mounted • Desktop mounted • Bulkhead mounted • Overhead mounted Refer to the display unit’s instruction manual for the compass safe distance.
  • Page 66 Simrad SP90 Loudspeaker Choosing a location and installation of the loudspeaker should be done with regard to utility. The compass safe distance must be allowed for when planning the unit’s location: • Standard compass: TBD m. • Steering Compass: TBD m.
  • Page 67: Display Unit

    → Refer to page 5 for more information about the displays available from Simrad. Mount the display as described in its respective manual. Related topics →...
  • Page 68: Sonar Operating Panel

    Simrad SP90 Sonar Operating Panel Observe the following procedure. To ensure correct operation, tick off every item when the action has been carried out. Mount the Sonar Operating Panel in an almost horizontal position to facilitate operation of the trackball.
  • Page 69: Sonar Processor Unit (Mc70)

    Wheelhouse units Sonar Processor Unit (MC70) The MC70 Sonar Processor Unit should be mounted on the deck or shelf inside a console, cabinet or desk. It must be mounted close to the Sonar Interface Unit, Operating Panel and display unit. Provide enough space for easy access to the cabling at the rear of the unit and for removal of the front lid.
  • Page 70: Sonar Interface Unit

    Simrad SP90 Sonar Interface Unit The Sonar Interface Unit should be mounted vertically with the cable inlet downwords on a side wall inside a console, cabinet or desk. It must be mounted close to the Sonar Processor Unit, Operating Panel and display unit.
  • Page 71: Loudspeaker

    Wheelhouse units Loudspeaker The loudspeaker should be mounted on the deckhead or anywhere practical close to the display unit. Provide enough space for easy access to the cabling. Observe the following procedure. To ensure correct operation, tick off every item when the action has been carried out. Prepare the mounting location.
  • Page 72: Cable Layout

    /or classification society. If no such guide-lines exist, Simrad AS recommends that Det Norske Veritas (DNV) Report No. 80-P008 «Guidelines for Installation and Proposal for Test of Equipment» be used as a guide.
  • Page 73: System Cabling

    • Corresponding terminations System and shipyard cables Cables fall into two categories: • System cables supplied by Simrad with the standard SP90 system delivery. • Shipyard cables provided by the shipyard performing the installation, or the shipowner. Cables to be provided by the installation shipyard are specified in the cable specifications.
  • Page 74: Sp90 Cable Plan

    List of cables (1) = Wheelhouse SP90/C1: Power to display monitor (2) = Sonar room SP90/C2: Display monitor SP90/C3: Power to Sonar Processor Unit List of units SP90/C4: Control (A) = Display monitor SP90/C5: Serial line (B) = Sonar Processing Unit...
  • Page 75 Cable layout Figure 15 SP90 Cable plan 851-164510 / Rev.E...
  • Page 76: Cable Specifications

    Simrad SP90 Cable specifications The list below specifies each cable used on the SP90 sonar. References are made to detailed cable drawings and specifications. Note that the Sonar Processor Unit provides a large number of connectors that are not used by the SP90 sonar. Those connectors are left out of the list below.
  • Page 77 Cable layout SP90/C7 Operating panel (USB) This is a standard USB data cable used between the Sonar Processor Unit and the Operator Panel. It is provided by Simrad. → Cable details on page 200. SP90/C8 Keyboard A This is a special “dual” cable. It is used from the Operating Panel (where it plugs into a common socket) to both the Sonar Processor Unit and the Sonar Interface Unit.
  • Page 78 Therefore, any surplus of the C15 cable can be used. → Cable details on page 195 SP90/C18 AC mains to Transceiver Unit This is a standard AC mains cable. It is provided by Simrad. → Cable details on page 196 SP90/C19 - Motor control mains This cable provides AC mains to the Motor Control Unit.
  • Page 79: Wheelhouse Cabling

    Jx tags. Note: The Sonar Processor Unit provides a large number of connectors that are not used by the SP90 sonar. Connections to the Sonar Interface Unit are made on the terminal blocks and connectors on the main circuit board. To access to connectors, open the unit’s lid.
  • Page 80 Simrad SP90 Connections The illustrations below identify the main connectors on the Sonar Processor Unit and the Sonar Interface Unit. Figure 16 Connections to the SP90 Sonar Processing Unit Figure 17 Connections to the SP90 Sonar Interface Unit 851-164510 / Rev.E...
  • Page 81 This is a standard mains supply cable. It is included in the delivery with the optional Simrad display units. The mains voltage for the Simrad LCD monitors is 115 or 230 Vac, and they will automatically sense the current supply voltage. For other type of displays, refer to the applicable documentation.
  • Page 82 C4 - Sonar Interface Control This cable holds the control signals between the SP90 Sonar Processor Unit and the SP90 Sonar Interface Unit. The cable is pre-connected to the Sonar Interface Unit, and it is equipped with a 37-pin female Delta connector in the Sonar Processor Unit end.
  • Page 83 Cable layout C5 - Sonar Interface Serial This cable holds the serial line fed from the SP90 Sonar Interface Unit to the SP90 Sonar Processor Unit. The cable is pre-connected to the Sonar Interface Unit, and is equipped with a special multi-connector in the Sonar Processor Unit end. The cable length is 1.2 m.
  • Page 84 Sonar Processor Unit. Figure 18 Connections to the rear side of the SP90 Sonar Operating Panel Secure the USB connector and cable with a plastic strip (A) and the self-adhesive support plate already provided.
  • Page 85 Cable layout C8 / C9 - Operating panel (Power and serial) This is a special dual cable from the Sonar Operating Panel to the Sonar Processor Unit and the Sonar Interface Unit. This dual cable has a common 15-pin Delta connector in the Sonar Operating Panel end, a 9-pin female Delta connector in the Sonar Processor Unit end (cable C8), and a 9-pin male Delta connector in the Sonar Interface Unit end (cable C9).
  • Page 86 This cable must not be spliced. If it is not long enough, or if an accident occurs to it, contact your local dealer or Simrad for advice. Do not connect the plug to the Sonar Interface Unit.
  • Page 87: Sonar Room Cabling

    Note: Due to the flexible shock mounting, all cables connected to the Transceiver Unit must have appropriate slack to allow for approximately 10 cm cabinet movement in all directions. Figure 20 SP90 Transceiver Unit cable connections 851-164510 / Rev.E...
  • Page 88 Simrad SP90 C17 - Motor control This cable is connected between the Transceiver Unit and the Motor Control Unit mounted on the Hull Unit. Use the surplus of cable C15, or an equivalent type of cable. Observe the following procedure. To ensure correct operation, tick off every item when the action has been carried out.
  • Page 89 Cable layout Figure 22 Connections to the Motor Control Unit References → Cable termination details (W235), page 195 → Motor Control Unit interior, page 77 → Transceiver Unit, cable gland locations, page 75 → Motor Control Unit interior, page 77 →...
  • Page 90 Simrad SP90 C15 - Sonar Interface Unit This is the control and data cable from the SP90 Sonar Interface Unit in the wheelhouse to the Transceiver Unit in the sonar room. The cable is included in the standard delivery, with a length of 100 meters, and has a pre-connected plug in the wheelhouse end.
  • Page 91 Cable layout C19 - AC power for hoist/lower motor This cable is used for the 3-phase mains supply for the hoisting and lowering motor on the Hull Unit. The cable’s specifications are shown in the referenced cable drawing. The connections are made to the Motor Control Unit.
  • Page 92 Simrad SP90 C18 - AC power to the Transceiver Unit This cable is included in the delivery. It is used for the mains supply to the Transceiver Unit. The mains power can be 115 or 230 Vac. Observe the following procedure for the connection of the mains power.
  • Page 93 Cable layout Connect the mains power cable from the C18 mains connector at the bottom of the Transceiver Unit to a normal mains outlet in the sonar room. - If the delivered cable connector does not fit use an adaptor, or replace with a suitable plug. References →...
  • Page 94 Simrad SP90 C16 - Transducer cable The transducer cables are provided by Simrad.They are physically connected to the top of the transducer shaft. Caution: Do not mount the flexible transducer cable to the Transceiver Unit. This will be described later.
  • Page 95: Cable Details

    Cable layout Cable details The following drawings show the cable details. → C1 - W301 AC power, page 196 → C2 - W500 VGA cable, page 199 → C3 - W301 AC power, page 196 → C4 - W206A Sonar Interface Unit Control, page 188 →...
  • Page 96: Basic Cabling Requirements

    Simrad SP90 Basic cabling requirements Cable trays All permanently installed cables associated with the system must be supported and protected along their entire lengths using conduits and/or cable trays. The only exception to this rule is over the final short distance (max. 0.5 metre) as the cables run into the cabinets/units to which they are connected.
  • Page 97 Cable layout Radio Frequency interference All cables that are to be permanently installed within 9 m (30 ft) of any source of Radio Frequency (RF) interference such as a transmitter aerial system or radio transmitters, must, unless shielded by a metal deck or bulkhead, be adequately screened by sheathing, braiding or other suitable material.
  • Page 98 Simrad SP90 Electrical continuity must be ensured along the entire length of all cable coverings, particularly at joints and splices. In no case should the shielding of cables be used as the only means of grounding cables or units. Metallic casings, pipes and conduits must be grounded, and when fitted with joints these must be mechanically and electrically grounded locally.
  • Page 99: Peripheral Equipment

    Sonar Interface Unit before mentioned in a later chapter. Required inputs The SP90 sonar system requires input from both a speed log and a course gyro. Inaccurate data from either of these instruments will result in an incorrect indication of vessel and target movements.
  • Page 100 Simrad SP90 Physical connections to the Sonar Interface Unit The figure below shows the positions for the different auxiliary connections on the Sonar Interface Unit. (CD7014) Figure 24 Serial line connections to the Sonar Interface Unit TB1, TB2 and TB3 in the top row TB5, TB6 and TB7 in the bottom row TB1 through TB7 are all RS-232 serial line connections.
  • Page 101: Speed Log Connection

    Connecting peripheral equipment Speed log connection Overview The sonar can read the speed information from one of the following three sources (tick off for the type which will be connected): • Pulse log (200 pulses/nautical mile) • Speed log with RS-232 serial line output •...
  • Page 102 Simrad SP90 Speed log with RS-232 output The sonar can also read the speed log data from a RS-232 serial line with a standard NMEA 0183 telegram format. The telegram can contain both the speed and the course data. Refer to the cable connection drawing for termination of the serial line data in the Sonar Interface Unit.
  • Page 103: Course Gyro Connection

    Connecting peripheral equipment Course gyro connection Overview The SP90 sonar can read the course information from an RS-232 serial line. In case where only a 3-phase synchro or stepper signal is available, an optional Gyro Interface Unit must be used for converting these signals to RS-232 serial line format.
  • Page 104: D)Gps Connection

    Simrad SP90 (D)GPS connection A (D)GPS may be connected to the SP90 sonar to indicate the latitude and longitude position of the vessel, cursor, markers and targets. In addition to the navigational data, the (D)GPS may also be used for the input of the speed log information. Most...
  • Page 105: Echo Sounder Connection

    To provide depth information on the sonar, an echo sounder with standard NMEA 0183 output format (RS-232 serial line) may be connected. Most Simrad echo sounders have the depth output available on an RS-232 serial line. For connection to the echo sounder, refer to the applicable echo sounder documentation.
  • Page 106: Trawl System Connection

    Simrad SP90 Trawl system connection The SP90 sonar can read the trawl data from a Simrad FS Trawl sonar or ITI (Integrated Trawl Instrumentation) system. The communication is achieved using a RS-232 serial line. When connecting the FS Trawl sonar to the SP90 Sonar...
  • Page 107: Catch Monitoring System Connection

    Connecting peripheral equipment Catch monitoring system connection To provide purse seine depth information on the sonar’s display, Simrad PI30 or PI32 Catch monitoring systems may be connected. Refer to the cable connection drawing for termination of the serial line data in the Sonar Interface Unit.
  • Page 108: Current Meter

    Simrad SP90 Current meter The SP90 sonar can read the data from the following current meter systems: • Kaijo DCG-200 The interface is based on an RS-232 serial line. For connection to the current meter system, refer to the RS-232 output in the applicable current meter documentation.
  • Page 109: Radio Buoys

    Connecting peripheral equipment Radio buoys The SP90 sonar can read the data from one of the following GPS based radio buoy systems: • SERPE • Ariane • Ryokusei All these systems are interfaced by means of an RS-232 serial line.
  • Page 110: Trackball / Mouse Connection

    8.10 Trackball / mouse connection In addition to the standard operating panel, an extra trackball or mouse with USB interface may be connected to the SP90 Sonar Processor Unit. In such case, all sonar operation may be controlled from this device.
  • Page 111: Start-Up Procedures

    Start-up procedures 9 START-UP PROCEDURES Introduction The procedures in this chapter shall be carried out once all the hardware units have been installed, and the cabling is finished. When you perform the procedures, make sure that you only perform those tasks described, and in the given order. Also, check off every item in the procedure as you carry on.
  • Page 112: Check-List Before Start-Up Commences

    Check that the transducer plug is not connected to the left-hand side of the Transceiver Unit. Hull Unit Check that the ship’s mains fuses to the Hull Unit are disconnected. References → SP90 Transceiver Unit power system, page 101 851-164510 / Rev.E...
  • Page 113: Starting Up The Stand-By Power Supply

    Starting up the stand-by power supply In order to start up the sonar units, the +24 Vdc stand-by power supply in the Transceiver Unit must be started first. Figure 28 The SP90 Transceiver Unit power system Observe the following procedure to start up the stand-by power supply.
  • Page 114 Simrad SP90 Insert the mains fuses for the Transceiver Unit on the ship’s mains fuse box. Measure the mains voltage supplied to the Transceiver Unit. - Write down the measured voltage here: Supply voltage (Vac): Check that the voltage selector switches, S201 on the power supply and S203 on the HV power unit, correspond to the measured voltage (115 Vac or 230 Vac position).
  • Page 115: Starting Up The Hull Unit

    Start-up procedures Starting up the Hull Unit Introduction Observe the following procedure to start up the Hull Unit. To ensure correct performance, tick off every item when the action has been carried out. Warning: Before starting up the sonar equipment on a recently launched vessel, make sure the depth under the keel is sufficient for the transducer to be lowered safely.
  • Page 116 Simrad SP90 Functional check Before you start the functional check, make sure that the mains fuses for the hull unit has been disconnected in the fuse box. This check will only require the +24 Vdc standby power from the Transceiver Unit.
  • Page 117 Start-up procedures Locate the hand crank inside the Motor Control Unit, and mount the hand crank onto the stub shaft through the hole in the top cover. Locate the brake release screw on the motor, and use an 4 mm Allen key to tighten up the screw until the motor brake is mechanically released (approximately 2 - 3 turns clock- wise).
  • Page 118 Simrad SP90 Set the hoisting/lowering switch S302 to Hoist position, and check that the hoisting contactor K301 is activated when pressing the hand crank safety switch S303. Set the hoisting/lowering switch S302 to the Lower position and check that the lowering contactor K302 is activated when pressing the hand crank safety switch S303.
  • Page 119 Start-up procedures Remove the cover for the mains connection to the motor. → Refer to figure 31 on page 107. Rearrange the motor connections so that they correspond to the measured voltage. 230 Vac 380 / 440 Vac Figure 31 Mains connection to the motor Adjust the release current on the motor overload switch...
  • Page 120 Simrad SP90 If the transducer shaft was hoisted, perform the following procedure: a Disconnect the ship’s 3-phase mains fuses b Change two of the connections to the terminals on the motor overload switch S301. c Reinsert the 3-phase mains fuses in the ship’s fusebox.
  • Page 121: Starting Up The Wheelhouse Units

    Starting up the wheelhouse units Introduction If the AC mains plug on the SP90 Sonar Processor Unit has been disconnected, the initial start of the sonar must be made by pressing the start switch S101. This switch is located behind the small lid on the front panel of the Sonar Processor Unit.
  • Page 122 Simrad SP90 Display set-up Observe the following procedure to set up the display and retrieve simulated sonar echoes. Refer to the instruction manual for the display unit, and adjust the picture size so the grey picture frame is shown in the outmost part of the display frame.
  • Page 123: Checking The Operating Panel

    Start-up procedures Checking the Operating Panel Introduction The simulated echoes makes it possible to test out most of the operational functions without starting up the Transceiver Unit. Figure 33 The Sonar Operating Panel 851-164510 / Rev.E...
  • Page 124 Simrad SP90 Functional test Observe the following procedure to check a selection of the operational functions. Markers Check the Target Marker. a Use the trackball on the Operating Panel, and move the cursor to the echo area. b Press the Target Marker button (field 2, top button).
  • Page 125 Start-up procedures Check the Seine circle. a Press the Gear button (field 2, bottom button). b Check that a Seine circle appears next to the ship symbol. c Press again to bring up the Ship Marker at the ship symbol. d Press a third time to remove the Seine circle.
  • Page 126: Full Screen

    Simrad SP90 Full screen Check the Full screen function. a Press the Menu button (field 6, left button) b Check that the menu disappears for a Full Screen echo presentation. c Press the button once again to recall the menu.
  • Page 127 Start-up procedures Off centre Check the Off centre function. a Move the cursor to any position inside the echo area. b Press the Off Centre button (field 8). c Check that the ship’s symbol changes its position to where the cursor is. d Select Mode 2 and then Mode 1 to move the ship symbol back to the screen centre.
  • Page 128 Simrad SP90 Operating Panel backlight Check the Operating Panel backlight. a Select the Display menu. b Press the left and right hand side of the Panel Backlight menu button. c Check that the Operating Panel backlight can be decreased and increased.
  • Page 129: Checking The Hoisting/Lower System

    Start-up procedures Checking the hoisting/lower system Introduction The following set of procedures requires two persons. One person must be stationed on the bridge to operate the sonar, while one must stay in the sonar room to make sure the hoisting/lowering system works properly. Proper communication exists between the two locations is useful.
  • Page 130 Simrad SP90 Checking the bridge functions Note: This procedure must be performed simultanously with the next procedure; Checking the sonar room functions. The instructions marked Sonar room: are performed in the sonar room. Check that the depth under the keel is sufficient to safely lower the transducer.
  • Page 131 Start-up procedures b Check that the LED next to the Down button starts to flash, and that the audible signal indicates transducer movement. c When lower position has been reached, check that the LED next to the Down button illuminates continuously, that the audible signal stops, and that the upper button in the Status menu shows Transducer: DOWN.
  • Page 132 Simrad SP90 b Check that the LED next to the Up button starts to flash, and that the audible signal indicates transducer movement. c When upper position has been reached, check that the LED next to the Up button illuminates continuously, that the audible signal stops, and that the upper button in the Status menu shows Transducer: UP.
  • Page 133 Start-up procedures Blank page This page is intentionally left blank. It allows you to remove the next test procedure from the manual, and bring it down to the sonar room during the procedure. 851-164510 / Rev.E...
  • Page 134 Simrad SP90 Checking the sonar room functions Note: This procedure must be performed simultanously with the procedure and checklist in the previous chapter; Checking the bridge functions. The instructions marked Bridge: are performed on the bridge. Note that these procedures are more detailed that what is presented here.
  • Page 135: Starting Up The Transceiver Unit

    Figure 35 The service switches, fuses, lamps and LEDs on the power supplies in the SP90 Transceiver Unit. Remove the fuses F204 and F205 from the HV Power unit’s front panel. Set the service switch S202 on the power supply to Service position to start up the Transceiver Unit.
  • Page 136 Simrad SP90 Check that the following small LEDs on the Transceiver Interface Board (TIB) illuminate (refer to the indication on the front of the power supply): - +8 V, -8 V, +5VA, -5 AV, +5 V, +12 V, +24 V and +24 V stand-by.
  • Page 137: Self-Noise Test

    Start-up procedures Self-noise test This test procedure will allow you to check the system’s self-noise. Observe the following procedure to prepare for the self-noise test. Start up the sonar. Select the following parameters in the menu system to execute a self-noise test of the sonar installation. a Select the Setup menu.
  • Page 138: System Start-Up

    Simrad SP90 9.10 System start-up Introduction To do the final tests, the vessel must be in the sea. This is because the transducer always must be in water before you start transmitting. Warning: If the sonar system starts transmitting while the...
  • Page 139 Start-up procedures Actions on the bridge Note: This procedure must be performed simultanously with the next procedure; Actions in the sonar room. The instructions marked Sonar room are performed in the sonar room. Start up the sonar. Check that the depth is sufficient for lowering of the transducer.
  • Page 140 Simrad SP90 Blank page This page is intentionally left blank. It allows you to remove the next test procedure from the manual, and bring it down to the sonar room during the procedure. 851-164510 / Rev.E...
  • Page 141 Start-up procedures Actions in the sonar room Note: This procedure must be performed simultanously with the previous procedure; Actions on the bridge. The instructions marked Bridge are performed on the bridge. Bridge: Start up the sonar. Bridge: Check that the depth is sufficient for lower the transducer Bridge: Lower the transducer to middle position by giving a short press on the middle...
  • Page 142: Alignment Of The Sonar Picture

    Simrad SP90 9.11 Alignment of the sonar picture Independent of the hull unit orientation, the alignment is always defined as: • the angle measured clockwise from the bow to the 0 degrees transducer mark. The 0 degrees transducer mark is located outermost on the mounting flange, and it is marked as a red “0”.
  • Page 143 Start-up procedures Turn the echo picture on the display in the following way: a Select the Setup menu. b Press the Test... to bring up the System test menu. c Press the Installation Menu button, and observe the menu appears on the top of the display. d Select Installation on the Installation menu, and then Alignment.
  • Page 144: Adjusting The Stabilisation Sensor Offset

    Simrad SP90 9.12 Adjusting the stabilisation sensor offset Independent of the hull unit orientation, the offset of the stabilization sensor is always defined as: • the angle measured clockwise from the 0 degrees transducer mark to the 0 degrees reference for the stabilization sensor.
  • Page 145 Start-up procedures Procedure: To enter the stabilisation offset angle Observe the following procedure to enter the offset stabilization angle as a parameter into the sonar system. Select the Setup menu Press the Test... to bring up the System test menu. Press the Installation Menu button, and observe the menu appears on the top of the display.
  • Page 146: Setting Own Ship Parameters

    Simrad SP90 9.13 Setting own ship parameters Ship dimensions To get the correct size of the vessel symbol on the display, the length and width have to be adjusted in the following way: Select the Setup menu. Press the Test... button to bring up the System test menu.
  • Page 147 Start-up procedures Observe the following procedure for transducer and GPS antenna positioning. Ensure that the Installation menu is visible at the top of the sonar display. - If not, refer to the first procedure in this chapter. Select Own Ship on the Installation menu, then Instrument Position Offsets, and finally Transducer.
  • Page 148: Testing The Peripheral Equipment

    Simrad SP90 10 TESTING THE PERIPHERAL EQUIPMENT 10.1 Introduction The physical connections of the peripehral sensors has been previously described. This chapter describes how the sonar system shall be set up to accept the signals from the sensors. Topics →...
  • Page 149: Interface Settings

    Testing the peripheral equipment 10.2 Interface settings Default interface settings The sensor settings are all preset to these recommended connections. Sensor Type Port Baudrate Talker Trawl system 4800 None 4800 None Echo sounder NMEA 4800 None Purse seine system PI30 4800 None Position system...
  • Page 150 Simrad SP90 Press Close to finish. If you enter a wrong value and the sensor interface does not work, you can change the parameters settings as many times as you wish. The final settings you make are automatically saved when the sonar system is switched off.
  • Page 151 Testing the peripheral equipment Figure 41 The Object Inspector Select SensorIOControl on the list by pressing on the + sign in front of the title, and then HWPortManager in the same way. Observe the list of communication ports. Press the + sign in front of the actual serial port. Press the COM symbol under the serial port.
  • Page 152: Speed Log

    Simrad SP90 10.3 Speed log Introduction The speed log can come from three different sensor types. Tick off for the type which will be connected. • Pulse log (200 pulses/nm) • Speed log (RS-232 serial line) • (D)GPS Refer to the selected speed log source in the following text.
  • Page 153 Testing the peripheral equipment Speed log with RS-232 serial line Observe the following procedure to test the speed log input: Access the I/O Setup menu. Select Sensors in the I/O Setup menu, then Speed and finally Speed Log. Observe the Sensor Config submenu appears at the bottom of the menu field.
  • Page 154: Course Gyro

    Simrad SP90 10.4 Course gyro Introduction The heading can come from two different sensor types. Tick off for the type which will be connected. • Course gyro • (D)GPS Note that the heading information from a GPS is generally too inconsistent to provide a stable sonar presentation.
  • Page 155 Testing the peripheral equipment Heading data from (D)GPS If the GPS is used for the course gyro input, wait with this test until the GPS position data are tested. Use the following procedure for testing the GPS input: Access the I/O Setup menu. Select Sensors in the I/O Setup menu, then Heading and finally Gyro.
  • Page 156: D)Gps

    Simrad SP90 10.5 (D)GPS Observe the following procedure to test the GPS input: Access the I/O Setup menu. → A procedure for this is located on page 137. Select Sensors in the I/O Setup menu, then Pos.System, and finally GPS.
  • Page 157: Echo Sounder

    Testing the peripheral equipment 10.6 Echo sounder The SP90 Sonar Processor Unit can read the depth information from an echo sounder on standard NMEA 0183 RS-232 serial line format. Observe the following procedure to test the echo sounder interface. Access the I/O Setup menu.
  • Page 158: Trawl System

    Simrad SP90 10.7 Trawl system Observe the following procedure to test the trawl system interface. Access the I/O Setup menu. → A procedure for this is located on page 137. Select Sensors in the I/O Setup menu, then Trawl System, and finally ITI or FS3300.
  • Page 159: Catch Monitoring System

    Testing the peripheral equipment 10.8 Catch monitoring system Observe the following procedure to test the catch monitoring system interface. Access the I/O Setup menu. → A procedure for this is located on page 137. Select Sensors in the I/O Setup menu, then Seine System, and finally ITI or PI30.
  • Page 160: Radio Buoy System

    Simrad SP90 10.9 Radio buoy system Observe the following procedure to test the radio buoy system interface. Access the I/O Setup menu. → A procedure for this is located on page 137. Select Sensors in the I/O Setup menu, then BuoySystem, and finally Buoy NMEA.
  • Page 161: Current Meter System

    Testing the peripheral equipment 10.10 Current meter system Observe the following procedure to test the Current Meter system interface. Access the I/O Setup menu. → A procedure for this is located on page 137. Select Sensors in the I/O Setup menu, then Current meter, and finally Kaijo.
  • Page 162: Final Tests And Measurements

    Simrad SP90 11 FINAL TESTS AND MEASUREMENTS 11.1 Introduction In order to verify that the sonar works properly, the following measurements and tests must be carried out: → Source Level (SL) measurements, page 151. → Receiving voltage response (VR), page 156.
  • Page 163: Source Level (Sl) Measurements

    Final tests and measurements 11.2 Source level (SL) measurements Preparations The procedure calls for a test hydrophone. Prior to use, fill in the technical specifications and the appropriate environmental specifications for the hydrophone to be used. Use the table provided. →...
  • Page 164 Simrad SP90 Transceiver Unit E201 46 49 Oscilloscope enable External trigger Vertical input Transducer Hydrophone 5 to 10 meters (CD5873) 0.5 ms t (ms) Up-p TX enable Figure 42 Source Level (SL) measurements Test procedure Observe the following procedure to make the source level measurements.
  • Page 165 Final tests and measurements Enter the result into the Measurements results table. → The Measurement results table is shown as table 4 on page 154. Read the peak-to-peak value of the transmitter pulse U(p-p). Enter the results into the Measurements results table. →...
  • Page 166 Simrad SP90 Measurements/calculations Value Unit Example Measured time delay (t) msec Distance from hy- r = 1.5xt meter drophone to trans- drophone to trans- 20 log r 17.5 ducer Hydrophone voltage U(p--p) volt in Omni in Omni U(RMS) = U(p--p)/2/√2 volt 0.32...
  • Page 167 Final tests and measurements Measurement termination The Source Level measurements have now been completed. Note: DO NOT remove the hydrophone from the position used for the source level measurements. This known position should also be used for the receiving voltage response (VR) measurements in the next chapter.
  • Page 168: Receiving Voltage Response (Vr)

    Simrad SP90 11.3 Receiving voltage response (VR) Preparations In order to measure the receiving voltage response, use the test hydrophone in the same position as for the previous source level measurements. Use the following menu settings on the sonar. Select the Setup menu.
  • Page 169 Final tests and measurements Enter the measured hydrophone voltage U(p-p) into the Measurement and calculation results table, and calculate the U Hydr voltage in the same table. → Refer to table 6. Measurements/calculations Value Unit Example Noise level --25.2 Hydrophone voltage U(p--p) volt U(RMS) = U(p--p)/2√2...
  • Page 170 Simrad SP90 Measurement termination The voltage response measurements have now been completed. Remember to restore all menu settings to normal operational standard. 851-164510 / Rev.E...
  • Page 171: Noise/Speed Curve

    11.4 Noise/speed curve Preparations In order to make a noise/speed curve for the ship, make the following settings in the SP90 menu. Select the Setup menu. Push the Test... button to access the System Test menu. Push the Test Config button, and observe the Test Config submenu appear at the bottom of the menu field.
  • Page 172 Simrad SP90 Speed Bearing (Knots) (Knots) - -120° - -60° 0° +60° +120° +180° Table 8 Noise measurements When the measurements are finished, make a plot of the noise for 0 degrees bearing into the Noise speed plot. - The noise level at full speed should preferably not exceed the 0 dB line.
  • Page 173 Final tests and measurements From full speed, reduce the engine thrust for minimum speed, and make similar readouts for Retardation. Speed Bearing 0 degrees (Knots) (Knots) Stable speed Acceleration Retardation Table 9 Noise verification Make a dashed line plot of the acceleration noise into the Noise/speed plot, and a dotted line for the retardation noise.
  • Page 174 Simrad SP90 NOISE/SPEED CURVE FOR 0° BEARING WITH MAXIMUM GAIN _________STABLE SPEED ---------ACCELERATION ..RETARDATION RETARDATION KNOTS Figure 43 Noise speed plot 851-164510 / Rev.E...
  • Page 175: Technical Specifications

    Technical specifications 12 TECHNICAL SPECIFICATIONS 12.1 Introduction The main technical specifications related to sonar installation are provided. Topics → Power specifications, page 164 → Weights and dimensions, Electronic units, page 165 → Weights and dimensions, Hull unit, page 166 → Environmental specifications, page 167 →...
  • Page 176: Power Specifications

    Simrad SP90 12.2 Power specifications Sonar Processor Unit MC70 • Voltage: - Nominal: 115 / 230 Vac, single phase (selectable) - Deviation: 15 % of nominal voltage - Transient: 20 % of nominal voltage, recover time 3 s • Power consumption: 150 VA •...
  • Page 177: Weights And Dimensions

    Technical specifications 12.3 Weights and dimensions Electronic units Operating Panel • Weight: Approximately 4 kg • Dimensions (WDH): 385 x 165 x 58 mm Sonar Processor Unit MC70 • Weight: Approximately 15 kg • Dimensions (WDH): 452 x 410 x 267 mm Sonar Interface Unit •...
  • Page 178 Simrad SP90 Hull Unit • Weight: - SP90: Approximately 850 kg (only on special delivery) - SP91: Approximately 900 kg (only on special delivery) - SP92: Approximately 850 kg - SP93: Approximately 900 kg • Dimensions: Refer to outline drawing Optional trunk •...
  • Page 179: Environmental Specifications

    Technical specifications 12.4 Environmental specifications Sonar Processor Unit MC70 • Operational temperature: 0 to +40°C • Storage temperature: -40 to +70°C • Humidity: 5 to 95% relative non-condensing Sonar Interface Unit • Operational temperature: 0 to +40°C • Storage temperature: -40 to +70°C •...
  • Page 180: Telegram Formats

    All transmissions take place as telegrams with data sentences, where each telegram has a defined format and length. All interfaces to and from the SP90 will be described in detail in this chapter. The table below provides an overview of the different telegrams received from the peripherals.
  • Page 181: Nmea 0183

    The following approved sentence structure are used for all NMEA data: $aaccc,c—c*hh<CR><LF> For some telegrams received from other Simrad equipment, the $ character is replaced by the @ character. According to the NMEA standard, the checksum field may not be used.
  • Page 182 Simrad SP90 Gyro The sonar can receive the following gyro telegrams. • Heading, magnetic • Heading, true Heading, magnetic $??HDM,x.x,M,,<cr><lf> where (from left towards right): Component Content Talker identifier code for the type of system used heading in degrees magnetic Heading, true $??HDT,x.x,M,,<cr><lf>...
  • Page 183 Technical specifications Speed log The SP90 can interface to an external speed log via Ethernet, or a serial line using the NMEA 0183 standard for reception of the vessel speed. The sonar will receive the following proprietary and standard NMEA telegrams: •...
  • Page 184 Simrad SP90 Time The SP90 software provides an interface to an external time synchronisation unit. The communication can take place via Ethernet, or on a serial line using the NMEA 0183 standard for reception of clock information. The SP90 will receive the following NMEA telegram: •...
  • Page 185 Technical specifications Trawl systems The SP90 interfaces a trawl system via Ethernet or on a serial line. The serial interface uses either the NMEA 0183 standard, or Simrad’s version of it. In the Simrad version of NMEA telegrams, the Start Of Sentence delimiter $ is replaced with @.
  • Page 186 Simrad SP90 Trawl position in cartesian co-ordinates @IITPC,x,M,y,M,z,M<cr><lf> where (from left towards right): Component Content Trawl position in cartesian co--ordinates Horizontal distance from vessel centre line Horizontal distance from the transducer to the trawl along the vessel’s centre line Depth of the trawl below the water surface Trawl position in latitude and longitude $IIGLLddmm.hh,N,dddmm.hh,W,hhmmss.ss,A<cr><lf>...
  • Page 187 Technical specifications Trawl headrope to footrope and bottom @IIHFB,x.x,M,y.y,M<cr><lf> where (from left towards right): Component Content Distances from the headrope to the footrope and bottom x.x,M Distance from headrope to footrope Distance from headrope to bottom Trawl door spread @IITDS,x.x,M<cr><lf> where (from left towards right): Component Content...
  • Page 188 Simrad SP90 Trawl to shoal distance @IITTS,x,M,y,P,z,M<cr><lf> where (from left towards right): Component Content Trawl to shoal distance Horizontal distance from the trawl to the shoal in a direction normal to the vessel’s centre line Horizontal distance from the trawl to the shoal the direction of the vessel’s centre line...
  • Page 189 Technical specifications ITI Outputs The SP90 transmits the following NMEA telegrams to the ITI system. • Tracked target position or marker Tracked target position or marker @SSTPP,xxxx,M,yyy,P,zzzz,M,nn<cr><lf> where (from left towards right): Component Content Scanning sonar Target position in polar coordinates...
  • Page 190 Simrad SP90 FS3300 Trawl system The serial output of the FS3300 system sends a 2-byte binary depth value. With a measurement in units of 0.1525879 m, the data format is: Osbbbbbb bbbbbbbb where (from left towards right): Component Content Indicates valid output when set Sign bit b...b...
  • Page 191 Technical specifications Global Positioning System (GPS) The SP90 can interface an external Global Positioning System (GPS) via Ethernet or by a serial line using the NMEA 0183 standard for reception of the present vessel position. The system will assume the position to be received in WGS84 datum.
  • Page 192 Simrad SP90 Global positioning system fix data $??GGAhhmmss.ss,ddmmhh,,N,dddmm.hh,W,hhmmss.ss,a, x,xx,x.x,x.x,M,x.x,M,x.x,xxxx<cr><lf> where (from left towards right): Component Content Code for the system used. OM = Omega, LC = Loran C etc Geographical latitude longitude hhmmss.ss UTC time ddmm.hh,N Latitude position in degrees, minutes and hun- dredths, N = North, S = South ddmm.hh,W...
  • Page 193 Technical specifications Echo sounder The SP90 interfaces an external echo sounder via Ethernet or a serial line for reception of depth information. The following echo sounder telegrams can be accepted. • Sounder depth below surface • Sounder depth below transducer •...
  • Page 194 Simrad SP90 Sounder depth below surface (Special) This telegram has been developed by Simrad. $SDDBS,,,y.y,M,,,tttttt<cr><lf> where (from left towards right): Component Content Talker Depth of water below surface Depth in meters ttttt Hardness 851-164510 / Rev.E...
  • Page 195 Technical specifications Sea current sensor The SP90 interfaces to an external sensor for reception of sea current data. The interface is made via Ethernet or on a serial line. Standard NMEA 0183 formats are used on the serial line. The SP90 receives the following NMEA telegrams: •...
  • Page 196 Simrad SP90 Wind sensor The SP90 interfaces an external wind sensor via Ethernet or a serial line using the NMEA 0183 standard for reception of the wind direction and speed. The SP90 can receive the following NMEA telegrams: • Wind direction and speed •...
  • Page 197 Technical specifications Wind speed and angle (relative) $??VWR,x.x,a,x.x,a,A<cr><lf> where (from left towards right): Component Content Talker Wind speed and angle Wind angle Wind speed, knots Knots Wind speed, m/s Wind speed, km/h km/h 851-164510 / Rev.E...
  • Page 198: Drawing File

    C25 - W208F Synchronisation, page 194 13.2 Installation drawings If required, certain drawings may be supplied on AutoCad format. To order, contact Simrad and refer to the drawing numbers in the bottom right corner of the frame. Bridge and sonar room units →...
  • Page 199 Drawing file Hull unit, outline dimensions → SP92 Hull Unit outline dimensions, page 207 → SP93 Hull Unit outline dimensions, page 208 Mounting trunk, outline dimensions → SP92 / SP93 Mounting trunk, (871-207481), page 209 Optional trunk, outline dimensions → SP92 / SP93 Optional trunk, outline dimensions, page 211 Blind cover, outline dimensions →...
  • Page 200 Simrad SP90 Internal control and communication cables These drawings detail the three cables used between the SP90 Sonar Processor Unit and the Sonar Interface Unit. All cables are provided by Simrad. Control and Serial The C4 and C5 cables are used between the Sonar Interface Unit and the MC70 Sonar Processor Unit.
  • Page 201 Drawing file C6 - Cheapernet communication This is the Cheapernet signal cable between the Sonar Interface Unit and the Sonar Processor Unit. The length is approximately 1.5 m. Note that one end of the cable is equipped with a “T-connection”. This end of the cable must be connected to the Sonar Processing Unit.
  • Page 202 Simrad SP90 Sonar Interface Unit Loudspeaker The loudspeaker cable is physically connected to the loudspeaker unit, and as such a part of the delivery. 851-164510 / Rev.E...
  • Page 203 Drawing file Serial lines The Sonar Interface Unit provides seven serial line communication ports. These are available on terminal blocks TB1 through TB7, and all are identical. For connection to the peripheral unit, refer to the applicable documentation for the unit in question.
  • Page 204 Simrad SP90 Pulse speed log This interface has been provided for a pulse speed log. This cable is not included with the delivery, and must be provided by the installation shipyard. Minimum cable specifications Conductors 2 x 0.5 mm2 Screen...
  • Page 205 Drawing file Transceiver Unit interface This is the main interconnection cable between the Sonar Interface Unit and the Transceiver Unit in the sonar room. The connection to the Sonar Interface Unit is made with the pre-fitted 25-pin Delta connector, which connects to J3. The connection to the Transceiver Unit is made on terminal block E201.
  • Page 206 Simrad SP90 Synchronization This cable allows external synchronization of the sonar’s transmission. This cable must be provided by the installation shipyard. Minimum cable specifications Conductors 4 x 0.5 mm2 Screen Overall braided Voltage 60 V Max.diameter Set by the plugs...
  • Page 207 Drawing file Transceiver Unit to Motor Control Unit This is the main intercommection cable between the SP90 Transceiver Unit and the Motor Control Unit on the Hull Unit. The connections to both the Transceiver Unit and the Motor Control Unit are made on terminal blocks.
  • Page 208 Simrad SP90 Standard AC power cable This cable is a standard three-wire power cable. It is commercially available in standard lengths, or may be produced locally to suit the specific installation needs. The instrument end is terminated in a standard IEC female socket, while the other end is terminated in a plug suitable for the local standard.
  • Page 209 Drawing file AC 3-phase mains to Hull Unit This cable is used to connect 3-phase AC power to the Motor Control Unit, and thus also to the hull unit’s hoist motor. The drawing also illustrates how to set up the motor connections to match the power available.
  • Page 210 Simrad SP90 Ethernet with RJ45 plugs (screened) This cable contains the Ethernet connection. RJ45 plugs are used to terminate the cable. Note that these plugs must be screened to comply to EC rules. 851-164510 / Rev.E...
  • Page 211 Drawing file Standard VGA cable This is a standard display cable used to connect the video signals. The cable is normally physically fastened to the display unit, and it is provided with the plug(s) readily attached. 851-164510 / Rev.E...
  • Page 212 Simrad SP90 Standard USB cable This is a standard commercial USB cable terminated with A and B plugs in either ends. The cable can be used for a variety of external devices. The order number provided is for a 4.5 m cable.
  • Page 213 Drawing file Operator panel This cable is used to connect the Operator Panel to the Sonar Processor Unit and Sonar Interface Unit. The cable is provided by the manufacturer. 851-164510 / Rev.E...
  • Page 214 Simrad SP90 SP90 Sonar Operating Panel - Outline dimensions 851-164510 / Rev.E...
  • Page 215 Drawing file SP90 Sonar Processing Unit (MC70) - Outline dimensions 851-164510 / Rev.E...
  • Page 216 Simrad SP90 SP90 Sonar Interface Unit - Outline dimensions 851-164510 / Rev.E...
  • Page 217 Drawing file SP90 Transceiver Unit - Outline dimensions 851-164510 / Rev.E...
  • Page 218 Simrad SP90 SP90 Standard loudspeaker - outline dimensions 851-164510 / Rev.E...
  • Page 219 Drawing file SP92 Hull Unit - Outline dimensions 851-164510 / Rev.E...
  • Page 220 Simrad SP90 SP93 Hull Unit - Outline dimensions 851-164510 / Rev.E...
  • Page 221 Drawing file SP92/SP93 Mounting trunk - Page 1 of 2 851-164510 / Rev.E...
  • Page 222 Simrad SP90 SP92/SP93 Mounting trunk - Page 2 of 2 851-164510 / Rev.E...
  • Page 223 Drawing file SP92/93 Optional trunk 851-164510 / Rev.E...
  • Page 224 Simrad SP90 SP92/SP93 Blind cover for sonar trunk 851-164510 / Rev.E...
  • Page 225: Installation Remarks

    Installation remarks 14 INSTALLATION REMARKS Use these pages to document comments and remarks concerning the installation. When the installation has been fully completed, and all functional tests have been perfomed to full satisfaction, representatives from all parties concerned must sign on the next page.
  • Page 226 Simrad SP90 --------------------------------------------------------- (Party / Date / Signature) --------------------------------------------------------- (Party / Date / Signature) --------------------------------------------------------- (Party / Date / Signature) 851-164510 / Rev.E...
  • Page 230 E 2005 Simrad AS ISBN-10: 82-8066-001-1 ISBN-13: 978-82-8066-001-5...

Table of Contents
