Mode Buttons

The button is located on the
Mode Buttons
This is simply a selector switch. Click on the button to select
Mode or User, and by this defining the operational function of
the four buttons on the Operating Panel.
Mode
Options
: The four
Mode Mode
used to select from your favourite modes.
: The four
User Mode
to select between four favourite user settings.
When the buttons on the Operating Panel are used to select
Mode
display modes, the four buttons will select the four top display
modes in the same order as they appear in the
Related topics
Sort Modes menu on page 97
Operating Panel 'Mode' field on page 75
Display menu on page 88
buttons on the Operating Panel can be
buttons on the Operating Panel can be used
Parameters
menu.
Display
menu.
Sort Modes
