Bearing (Display) - Simrad SX90 - REFERENCE MANUAL REV D Reference Manual

Parameters

Bearing (Display)

The parameter dialog opens when you click the
Bearing (Display)
button in the menu.
Bearing Display
Dialog description
This is simply a selector switch. Click on the button to select
True north or Relative Ship. Certain bearing data will change
their values accordingly. The following bearing data will change
when you switch between the two settings:
• Cursor bearing
• Markers bearing in the menu
Objects
• Target positions in the catch data views
Note
There are no indication on any of these read-outs to identify them
as relative or true.
All other bearing data remain permanent, and will not change
when you select relative or true bearing. This includes:
• Wind direction is always relative to true north
• Audio line is always relative to the ship's heading
• Ship's current heading is always relative to true north
• Target's current heading is always relative to true north
Related topics
• Display menu on page 88
• Objects menu on page 91
