GETTING STARTED

Power on/off procedures

22
Please find the basic information required to get you started up.
Topics
• Power on/off procedures on page 22
• How to perform basic operations on page 24
• Visual aids on page 29
• Cosmetics on page 30
• On-line help on page 32
These procedures explain how to switch the sonar system on
and off.
How to switch on the sonar
Press the
1
Power
2 Press the
Power
depressed for approximately two seconds.
• The green lamp on the right side of the button will flash
to indicated that the power has been switched on, and that
the computer is starting up.
• After a few seconds the Processor Unit starts up. Once
up and running, it automatically starts the Beamformer
Unit. You can observe the progress on the
dialog boxes that appear.
• After a short period (approximately 2 minutes) you will
see the sonar picture on the display.
3 Check that the water depth beneath the keel is sufficient to
lower the transducer.
4 Press the
Down
transducer.
• The green lamp next to the button will flash, and an
audible signal indicates that the transducer moves
downwards.
button on the colour display monitor.
button on the Operating Panel, and keep it
button on the control panel to lower the
TRU On/Off
307670/D
