CLI – This example sets the priority for MSTI 1, and adds VLANs 1-5 to
this MSTI.
Console(config)#spanning-tree mst-configuration
Console(config-mst)#mst 1 priority 4096
Console(config-mstp)#mst 1 vlan 1-5
Console(config-mst)#

Displaying Interface Settings for MSTP

The MSTP Port Information and MSTP Trunk Information pages display
the current status of ports and trunks in the selected MST instance.
Field Attributes
MST Instance ID – Instance identifier to configure. (Range: 0-4094;
Default: 0)
The other attributes are described under "Displaying Interface Settings,"
page 3-166.
Web – Click Spanning Tree, MSTP, Port Information or Trunk
Information. Select the required MST instance to display the current
spanning tree values.
S
PANNING

Figure 3-73 MSTP Port Information

T A
REE LGORITHM
C
ONFIGURATION
4-229
4-231
4-230
3-177
