C
ONFIGURING THE
CLI – The following example globally enables IP Precedence service on
the switch, maps IP Precedence value 1 to CoS value 0 (on port 1), and
then displays the IP Precedence settings.
Console(config)#map ip precedence
Console(config)#interface ethernet 1/1
Console(config-if)#map ip precedence 1 cos 0
Console(config-if)#end
Console#show map ip precedence ethernet 1/1
Precedence mapping status: disabled
Port
--------- ---------- ---
Eth 1/ 1
Eth 1/ 1
Eth 1/ 1
Eth 1/ 1
Eth 1/ 1
Eth 1/ 1
Eth 1/ 1
Eth 1/ 1
Console#
* Mapping specific values for IP Precedence is implemented as an interface
configuration command, but any changes will apply to the all interfaces on
the switch.

Mapping DSCP Priority

The DSCP is six bits wide, allowing coding for up to 64 different
forwarding behaviors. The DSCP replaces the ToS bits, but it retains
backward compatibility with the three precedence bits so that non-DSCP
compliant, ToS-enabled devices, will not conflict with the DSCP mapping.
Based on network policies, different kinds of traffic can be marked for
different kinds of forwarding. The DSCP default values are defined in the
following table. Note that all the DSCP values that are not specified are
mapped to CoS value 0.
3-212
S
WITCH
Precedence COS
0 0
1 0
2 2
3 3
4 4
5 5
6 6
7 7
4-278
4-187
4-278
4-282
