Configuring Global Settings - SMC Networks SMC8748ML3 Management Manual

---------------------------------------------------------------
Eth 1/ 1 information
---------------------------------------------------------------
Admin status:
Role:
State:
External admin path cost: 10000
Internal admin cost:
External oper path cost:
Internal oper path cost:
Priority:
Designated cost:
Designated port:
Designated root:
Designated bridge:
Fast forwarding:
Forward transitions:
Admin edge port:
Oper edge port:
Admin Link type:
Oper Link type:
Spanning Tree Status:
.
.
.
Note: The current root port and current root cost display as zero when
this device is not connected to the network.

Configuring Global Settings

Global settings apply to the entire switch.
Command Usage
• Spanning Tree Protocol
Uses RSTP for the internal state machine, but sends only 802.1D
BPDUs. This creates one spanning tree instance for the entire network.
If multiple VLANs are implemented on a network, the path between
specific VLAN members may be inadvertently disabled to prevent
network loops, thus isolating group members. When operating multiple
VLANs, we recommend selecting the MSTP option.
12. STP and RSTP BPDUs are transmitted as untagged frames, and will cross any VLAN boundaries.
