C
ONFIGURING THE
Web – Click Spanning Tree, STA, Information.
CLI – This command displays global STA settings, followed by settings
for each port.
Console#show spanning-tree
Spanning-tree information
---------------------------------------------------------------
Spanning tree mode:
Spanning tree enable/disable:
Instance:
Vlans configuration:
Priority:
Bridge Hello Time (sec.):
Bridge Max Age (sec.):
Bridge Forward Delay (sec.):
Root Hello Time (sec.):
Root Max Age (sec.):
Root Forward Delay (sec.):
Max hops:
Remaining hops:
Designated Root
Current root port:
Current root cost
Number of topology changes:
Last topology changes time (sec.): 13380
Transmission limit:
Path Cost Method:
3-160
S
WITCH

Figure 3-68 STA Information

MSTP
enable
0
1-4093
32768
2
20
15
2
20
15
20
20
32768.0.0000ABCD0000
1
200000
1
3
long
4-243
