CLI – This examples assigns an IP and MAC ingress ACL to port 1, and
an IP ingress ACL to port 2.
Console(config)#interface ethernet 1/1
Console(config-if)#ip access-group david in
Console(config-if)#mac access-group jerry in
Console(config-if)#exit
Console(config)#interface ethernet 1/2
Console(config-if)#ip access-group david in
Console(config-if)#

Port Configuration

Displaying Connection Status

You can use the Port Information or Trunk Information pages to display
the current connection status, including link state, speed/duplex mode,
and auto-negotiation.
Field Attributes (Web)
• Name – Interface label.
• Type – Indicates the port type. (1000BASE-T, SFP, or 10GBASE-LR)
• Admin Status – Shows if the interface is enabled or disabled.
• Oper Status – Indicates if the link is Up or Down.
• Speed Duplex Status – Shows the current speed and duplex mode.
(Auto, or fixed choice)
• Flow Control Status
use. (IEEE 802.3x, Back-Pressure or None)
• Autonegotiation – Shows if auto-negotiation is enabled or disabled.
• Media Type
combination ports 21-24. (Copper-Forced, SFP-Forced,
SFP-Preferred-Auto)
• Trunk Member – Shows if port is a trunk member.
5. There are interoperability problems between Flow Control and Head-of-Line (HOL) blocking for the
switch ASIC; Flow Control is therefore not supported for this switch.
6. Port Information only.
5
– Indicates the type of flow control currently in
6
– Shows the forced/preferred port type to use for
