C
ONFIGURING THE
CLI – This example shows the STA attributes for port 5.
Console#show spanning-tree ethernet 1/5
Eth 1/ 5 information
--------------------------------------------------------------
Admin status:
Role:
State:
External admin path cost: 10000
Internal admin cost:
External oper path cost:
Internal oper path cost:
Priority:
Designated cost:
Designated port:
Designated root:
Designated bridge:
Fast forwarding:
Forward transitions:
Admin edge port:
Oper edge port:
Admin Link type:
Oper Link type:
Spanning Tree Status:
Console#

Configuring Interface Settings

You can configure RSTP and MSTP attributes for specific interfaces,
including port priority, path cost, link type, and edge port. You may use a
different priority or path cost for ports of the same media type to indicate
the preferred path, link type to indicate a point-to-point connection or
shared-media connection, and edge port to indicate if the attached device
can support fast forwarding. (References to "ports" in this section means
"interfaces," which includes both ports and trunks.)
Command Attributes
The following attributes are read-only and cannot be changed:
• STA State – Displays current state of this port within the Spanning Tree.
(See Displaying Interface Settings on page 3-166 for additional
information.)
- Discarding - Port receives STA configuration messages, but does not
forward packets.
3-170
S
WITCH
enabled
disable
discarding
10000
10000
10000
128
10000
128.1
32768.0.0000E8AAAA00
32768.0.0030F1D473A0
disabled
2
disabled
disabled
auto
point-to-point
enabled
4-243
