SMC Networks SMC8748ML3 Management Manual page 644

C L
OMMAND INE
Example
Console#show spanning-tree
Spanning-tree information
---------------------------------------------------------------
Spanning tree mode:
Spanning tree enable/disable:
Instance:
Vlans configuration:
Priority:
Bridge Hello Time (sec.):
Bridge Max Age (sec.):
Bridge Forward Delay (sec.):
Root Hello Time (sec.):
Root Max Age (sec.):
Root Forward Delay (sec.):
Max hops:
Remaining hops:
Designated Root:
Current root port:
Current root cost:
Number of topology changes:
Last topology changes time (sec.): 22
Transmission limit:
Path Cost Method:
---------------------------------------------------------------
Eth 1/ 1 information
---------------------------------------------------------------
Admin status:
Role:
State:
External admin path cost: 10000
Internal admin cost:
External oper path cost:
Internal oper path cost:
Priority:
Designated cost:
Designated port:
Designated root:
Designated bridge:
Fast forwarding:
Forward transitions:
Admin edge port:
Oper edge port:
Admin Link type:
Oper Link type:
Spanning Tree Status:
. .
.
4-244
I
NTERFACE
MSTP
enable
0
1-4093
32768
2
20
15
2
20
15
20
20
32768.0.0000ABCD0000
1
10000
1
3
long
enable
root
forwarding
10000
10000
10000
128
200000
128.24
32768.0.0000ABCD0000
32768.0.0030F1552000
disable
1
enable
disable
auto
point-to-point
enable
