Displaying LACP Settings and Status for the Remote Side

You can display configuration settings and the operational state for the
remote side of an link aggregation.

Table 3-10 LACP Neighbor Configuration Information

Field
Partner Admin System
ID
Partner Oper System
ID
Partner Admin
Port Number
Partner Oper
Port Number
Port Admin Priority
Port Oper Priority
Admin Key
Oper Key
Admin State
Oper State
3-138
S
WITCH
Description
LAG partner's system ID assigned by the user.
LAG partner's system ID assigned by the LACP
protocol.
Current administrative value of the port number for the
protocol Partner.
Operational port number assigned to this aggregation
port by the port's protocol partner.
Current administrative value of the port priority for the
protocol partner.
Priority value assigned to this aggregation port by the
partner.
Current administrative value of the Key for the protocol
partner.
Current operational value of the Key for the protocol
partner.
Administrative values of the partner's state parameters.
(See preceding table.)
Operational values of the partner's state parameters. (See
preceding table.)
