2.7.4.2

Configuring a 1PPS Output

To configure a 1PPS output:
1. Navigate to
2. In the panel on the right, click the GEAR button next to the
3. The
4.
CHAPTER •
2 VersaSync User Manual Rev. 12
Offset: [-500000000 to 500000000 ns = ±0.5 s] Allows to offset
the system's 1PPS on-time point, e.g. to compensate for cable delays
and other latencies
4. Click Submit.
INTERFACES:
(white on orange).
want to edit.
1PPS Output Edit window will display, allowing the following items to be
configured:
Signature Control: Determines when the output is enabled. For more
information, see
Offset [ns]: Allows to offset the system's 1PPS on-time point, e.g. to com-
pensate for cable delays and other latencies [range = –500000000 to
500000000 ns = ±0.5 s]
Edge: Used to determine if the on-time point of the 1PPS output is the
rising or the falling edge of the signal.
Rising
Falling
Pulse Width [ns]: Configures the Pulse Width of the 1PPS output.
[range = 20 to 900000000 ns = 0.0 μs to 0.9 s]
[default = 200 ms]
Click Submit.
OUTPUTS, or to
"Signature Control" on
2.7 Configuring Inputs/Outputs
INTERFACES: OPTION CARDS
1PPS Output
page 69.
you
53
