1.5 Connectors and their Pinouts
Table 1-8:
Ref
POWER
I/O
ETH
SAASM,
FILL/Z
1.5.5.1 ODU
ETHERNET connector wiring:
POWER connector pinout
14
Connector Part Numbers
Description
Power connector,
5 pin
I/O connector, 26
pin
Ethernet con-
nector, 16 pin
Optional I/O con-
nector, 8 pin
®
ordering contact information (USA):
ODU-USA Inc.
4010 Adolfo Road
Camarillo, CA 93012
United States of America
Phone: +1 (805) 484 0540
Fax: +1 (805) 484 7458
Email: sales@odu-usa.com
Note: Building the mating cables requires special tools. Contact
ODU for cable assemblies. Be advised that typical lead times are 12
to 16 weeks.
1 through 8: A Ethernet Connect, 4 pairs, 1000bT (in the software, eth0)
9 through 16: B Ethernet Connect, 4 pairs, 1000bT (in the software, eth1)
1: V , 10 to 32 V
Main DC
2: -not used-
3: V , 10 to 32 V
Standby
VersaSync Connector
Orolia Part
ODU Part No.
No.
J240R- GK1YBR-
0051-002Q P05UJ00-000L
J240R- GK2YAR-
0261-002F P26UC00-
000L
J240R- GK1YCR-
0161-002F P16UC00-000L
J240R- GK1YDR-
0081-012F P08UF00-
000L
(Standby Power)
DC
CHAPTER
Mating (Cable) Connector
Orolia Part
ODU Part No.
No.
P240R- S11YBR-
0051-002Q P05XJG0-
0000
P240R- S12YAR-
0261-002F P26XCD0-
0000
P240R- S11YCR-
0161-002F P16XCD0-
0000
P240R- S11YDR-
0081-002F P08XFG0-
0000
•
1 VersaSync User Manual Rev. 12
