Figure 2-8:
The State displays the current PTP master state. The LED will change according
to the current state:
The Domain displays based on the current configuration.
The Datasets button
PTP Datasets Panel " on
The Statistics button
istics Panel" on
The Settings button
Edit PTP Settings Panel" on
The Delete button
will return all settings to default.
The Plus symbol
popup window..
CHAPTER •
2 VersaSync User Manual Rev. 12
PTP Master Overview Drop Down
Address: the IP or MAC address associated with the Ethernet port
Comm. Mode: the PTP transmission mode configuration (Unicast, Multicast,
or Hybrid).
Transport Mode: (Ethernet, UDP on IPv4, UDP on IPv6).
Profile: the currently selected PTP profile.
Clock Class: as reported by the PTP data.
Clock Accuracy: as reported by the PTP data.
Clock Identity: a unique identifier for the PTP instance.
Green: Master
Yellow: Listening, Passive
Red: Faulty
Grey: Disabled, Unknown
page 146).
displays the Statistics popup window (see
page 147).
brings up the popup window to edit settings (see
removes the configuration on a given Ethernet port and
adds a new PTP Master and brings up the Edit PTP Settings
2.8 Configuring Network Settings
displays the Datasets popup window (see
page 143).
"The
"The PTP Stat-
"The
