GPS-Denied Environments
VersaSync accommodates an OCXO, Rubidium, or CSAC oscillator, allowing the
unit to maintain frequency and time accuracy for long periods of GPS/GNSS out-
age. In addition, it can be re-synchronized by an external reference.
Reliable, Versatile, and Configurable
VersaSync physical inputs and outputs are software configurable and can adapt
to various application requirements. I/O pins can be configured as TTL, 10 V
pulse, RS232, RS422, and RS485. This allows VersaSync to provide a high number
of outputs of the same type, while still fitting into a small form factor. However, if
the combination of software configurable outputs is not enough, VersaSync can
accommodate an option board (within the same form factor), designed to cus-
tomer requirements to provide additional outputs of the same type or other type
of interface (IRIG AM, etc...).
Due to its high level of ruggedization, VersaSync provides very high intrinsic reli-
ability. Strong status monitoring capability, either locally or remotely, allows
quick fault diagnosis. Physical alarm (dry contact) and network alarms (SNMP
traps) are raised in real time. An internal, exportable log can be accessed either
locally or remotely. In addition to oscillator options (OCXO, Rubidium, or CSAC),
VersaSync is available with a C/A L1 GPS receiver or with an L1/L2 SAASM
receiver. Pulse outputs are configurable through the web user interface ("Web
UI"). An extension slot is available to accommodate additional timing interfaces.
Typical Applications
1.3

Status LEDs

VersaSync's front panel status LEDs provide a real-time status overview: Eight
(8) LEDs indicate the unit's current operating state:
CHAPTER •
1 VersaSync User Manual Rev. 12
Airborne: Observation payload (radars, optronics, electronic warfare), fly-
ing test bench, flight analysis
Ground: Satcom On the Move (SOTM), anti-IED jamming systems, mobile
radios and C3I, robotics
Marine: Sensor support (radars, sonars, optronics, electronic warfare), com-
munication networks, offshore/DSO platforms, buoys
1.3 Status LEDs
