2.7 Configuring Inputs/Outputs
58
ICD-153
EndRun
Once selected, the Format Group may offer a choice of Formats. For
more information on supported Formats, see
Formats" on page 319.
Format 1: Selects either the first of up to three, or the only
format message to be output.
Format 2: Selects the second consecutive format message to
be outputted. Select "None" if only one output format is
desired. "None" will be the only choice available if Format 1 is
"None."
Format 3: Selects the third consecutive format message to be
outputted. Select "None" if only one output format is desired.
"None" will be the only choice available if Format 2 is "None."
Signature Control: Signature Control controls when the selected
ASCII data output format will be present; see
page 69.
Output Mode: This field determines when the output data will be
provided. The available Mode selections are as follows:
Broadcast: The format messages are automatically sent out on
authorized condition (Signature control), every second a mes-
sage is generated in sync with the 1PPS.
Request (On-time): A format message is generated in sync with
1PPS after the configured request character has been received.
Request (Immediate): A format message is generated as soon
as the request character is received. As this selection does not
correlate the output data to the on-time point for the message,
in Data Formats that do not provide sub- second information
(such as Formats 0 and 1 whereas Format 2 provides sub-
second information), it should be noted that the output data
can be provided immediately, but a time error could occur
when using the on-time point of the message in addition to the
data for timing applications.
Note:
ined by the choices of Format Group and Format.
The choices available in this field are determ-
CHAPTER
"Time Code Data
"Signature Control" on
•
