Your new VLAN interfaces will now be displayed in the VLAN Setup panel, listed
as eth[#].[VLAN ID].
2.8.10

System Time Message

The System Time Message is a feature used for special applications that require a
once-per-second time message to be sent out by VersaSync via multicast. This
time message will be transmitted before every 1PPS signal, and can be used to
evaluate accuracy and jitter.
To set up and enable a System Time Message:
CHAPTER •
2 VersaSync User Manual Rev. 12
3. Select the parent interface [eth0-], type in your VLAN ID, and click submit.
Repeat the process as necessary.
1. Navigate to MANAGEMENT
2. Populate the fields
click Submit.
3. In the Network Services
> OTHER >
Multicast Address, Port Number
panel, enable System Time
2.8 Configuring Network Settings
System Time Message.
and Message
Message.
ID, and
107
