Figure 1-2:
The following interfaces are provided:
1.4.1

Input Timing Interfaces

Table 1-3:
1PPS
ASCII/HaveQuick/IRIG B
ASCII/NMEA
CHAPTER •
1 VersaSync User Manual Rev. 12
VersaSync front panel connectors
Note: VersaSync is highly configurable and the connections can be
adjusted many different ways. Your interface configuration may
vary based on options you selected during the ordering process.
VersaSync inputs (default setup)
INPUT SIGNAL
DCLS
Total
available
TTL 10V
(1) 1
(1)
(1)
1.4 Interfaces Overview
Connector
RS- RS-
ETH
232 485
1
1
No.
(see Fig.
above)
4
4
4
7
