4.3 Notifications
The alarm notification feature described below allows you to be notified of a
potential reception issue BEFORE the GNSS reference becomes invalid. This may
be useful e.g., to notify system operators of a deteriorating signal reception
before VersaSync loses the GNSS reference.
Note that VersaSync itself has a pre-defined minimum number of satellites that
must be tracked in order for GNSS to be considered a valid reference. The min-
imum number of satellites depends e.g., on your receiver mode, the GNSS signal
reception in the area where your antenna is located, and the type of receiver in
your unit. In Stationary mode, and for SAASM units, the minimum number of satel-
lites is normally 4 (four). Hence, it would be prudent to set the Minor Alarm
Threshold to 8, and the Major Alarm Threshold to 6.
To determine how many satellites your VersaSync unit is currently receiving, nav-
igate to INTERFACES > REFERENCES: GNSS 0. See also
Reference Status" on
To set the GPS Alarm Thresholds:
1. Navigate to
2. At the bottom of the window, locate the
3. In the
4. In the
238
Note: While GPS Notification Alarms can be used in
receiver mode, it is not advisable.
page 195.
MANAGEMENT > OTHER:
tab.
Minimum Satellites
must be available before the alarm is triggered. The alarm will be triggered
when the number of satellites available is
Duration Below Threshold (s)
the system must be below the threshold set in the
before an alarm is triggered. The alarm will be triggered when this time is
reached.
Notifications, and choose the
ALARM THRESHOLD
fields enter the minimum number of satellites that
BELOW
fields, enter the time
CHAPTER
Mobile GNSS
"Reviewing the GNSS
GPS
panel:
this number.
in seconds that
Minimum Satellites
•
4 VersaSync User Manual Rev. 12
field
