Receiver Mode:
Single Satellite: Used in areas with poor GNSS reception.
Standard: Default operating mode for the GNSS receiver.
Mobile: [default] For non-stationary applications.
Receiver Dynamics: (u-blox receivers only); see
Dynamics" on page 203.
Survey Progress: Real-time status:
ACQUIRING (x
SURVEYING (x %)—yellow; remains at 1% if no satellites are in view
COMPLETE—green
Number of Tracked
tracked.
Offset: As set by the user, in nanoseconds.
Antenna Sense:
OK (green)
Open: Check the antenna for the presence of an open.
Short: Check the antenna for the presence of a short circuit.
Position: VersaSync's geographic position by:
Latitude: In degrees, minutes, seconds
Longitude: In degrees, minutes, seconds
Altitude: In meters MSL (Mean Sea Level)
Receiver Constellation: GPS/GLONASS/Galileo/BeiDou/SBAS/QZSS
Client A-GPS Status: A-GPS is ENABLED and running, or DISABLED
Client A-GPS Data: External A-GPS data is AVAILABLE, or UNAVAILABLE
Server A-GNSS Status: The Rinex Server feature is ENABLED and running,
or DISABLED
Server A-GNSS Data: A-GPS data is AVAILABLE and can be downloaded
by clients, or it is UNAVAILABLE
Identified Satellite Signal
Color indicates signal strength.
With your mouse pointer, hover over a bar graph to display tool tip inform-
ation about satellite constellation, satellite number, and signal strength.
Satellites)—red
Satellites: The number of satellites currently being
Strengths: Bar graphs for all satellites detected.
