Safran VersaSync User Manual page 77

To configure one of the GPIO Outputs:
CHAPTER •
2 VersaSync User Manual Rev. 12
Rise Time to 90% of
Programmable Period: 100 ns to 1,000,000,000 ns in 5ns steps, to
60,000,000 µs in 1µs steps
Programmable Pulse
1. Navigate to INTERFACES > OUTPUTS: GP Output
Note: I/O ports are numbered starting with 0.
The GP Output Status window will display. It provides information on the
Output Mode, if the output is Enabled, and its Current Value (i.e., low or
high output level).
2. Click the Edit button in the lower left corner. The
offering the following settings:
Output Mode: This is a drop-down list, offering the following options:
Direct Output
the Output Value
1PPS: Output will occur at a rate of one pulse per second.
1PPM:Output will occur at a rate of one pulse per minute.
Square
wave determined by the configuration.
Custom: Output will be customized according to specific para-
meters.
Output Enabled: Check this box to enable or disable the output. If
Enabled, additional configurable parameters will be displayed.
If Direct Output mode is selected:
Signature Control: Controls when the output will be present. See
also: "Signature Control" on
Output Value: Determines if the output level shall be
Re-Initialize: Re-initializes square wave generation and aligns to 1PPS.
Level: <10 ns
Width: 20 ns to 900 ms with 5 ns resolution
Value: Output will be low or high determined by
selection below.
Wave: Output will generate a programmable square
page 69.
2.7 Configuring Inputs/Outputs
[x].
GP Output Edit will open,
High or Low.
63
