Legend, individual LEDs

Table 1-2:
CHAPTER •
1 VersaSync User Manual Rev. 12
FAST OFF
Legend for Status LEDs
Icon Light
OFF
HEARTBEAT
ON
OFF
HEARTBEAT
SLOW
FAST
ON
OFF
FAST
ON
OFF
ON
FAST
OFF
FAST
ON
OFF FAST
No power
Booting
Powered
No GNSS reception (0 satellites)
GNSS acquisition in process (≥ 1 satellite(s), or 1PPS OK, or
Time OK
Jamming detected
Antenna short circuit
GNSS is available as reference (1PPS and Time OK)
Inputs not detected/all inputs are disabled
1 or more input is missing, or invalid timing on 1 or more input
detected
Inputs are enabled
Unit is in Holdover (valid)
System Clock OK (valid)
Invalid Time (Holdover period exceeded, or oscillator dam-
aged)
No output signal(s) detected/all outputs are disabled
Malfunction detected (short circuit, or overload)
Outputs are enabled
