Test any new cables to safely power the unit before connecting your VersaSync
to any other inputs or outputs (such as a GNSS antenna), and before grounding
your unit to a vehicle.
1.5.2
Input/Output Connector
VersaSync has a 26- pin input/output connector that offers 8 software- con-
figurable CHANNELS, plus one fixed DCLS channel, and a USB interface. To learn
more about types of interfaces and signals, and how to configure them, see
"Assigning I/O Pins" on
Table 1-6:
Pin
1
2
3
4
CHAPTER
•
1
VersaSync User Manual Rev. 12
page 44.
Default I/O connector pinout
Channel
Signal
0
1PPS output (5V)
GND
1
Have Quick input
(RS-485 signal
+)
GND
1.5 Connectors and their Pinouts
Pin
Channel
15
7
Have Quick out-
put (RS-485 sig-
nal +)
16
GND
17
8
Have Quick out-
put (RS-485 sig-
nal –)
18
GND
Signal
11
