Monitoring BroadShield
You can use the BroadShield Web UI to monitor the jamming/spoofing status, or
the VersaSync Web UI. In the latter case, you will be informed of a Major Alarm,
as described below:
BroadShield Alarm
If BroadShield detects a jamming or spoofing event, VersaSync will emit a
BroadShield Critical, Major Alarm (see illustration below). VersaSync will go into
Holdover
vice setting (see
your VersaSync settings – will either remain in sync
it will continue to output time and frequency signals considered valid, or it will go
out of sync
You can also configure a notification alarm, see
BroadShield Service" on
BroadShield Web UI Monitoring
The BroadShield Web UI will also display real time signal status information, or a
map status.
To open the BroadShield user interface:
DASHBOARD
The Dashboard panel displays up to 7 days of history data, and a real-time amp-
litude frequency spectrum. The headline background color indicates the current
jamming/spoofing status: red= jamming or spoofing detected;
at this time
CHAPTER •
3 VersaSync User Manual Rev. 12
(yellow HOLD status light) and – depending on the BroadShield Ser-
"Enabling/Disabling the BroadShield Service" on
(red SYNC light).
Note: If at any time you receive an error message
to the unit, the VersaSync Web UI may have timed out (see
Timeout" on
1. Navigate to TOOLS: SYSTEM > Broadshield.
2. The embedded Broadshield Web UI will open, displaying the Dashboard
and providing access to the following panels:
page 186.
page 249). Refresh your browser page to log back in.
