2.8.2

Network Ports

Ports act as communication endpoints in a network. The hardware configuration
of your unit will determine which ports (e.g., Eth0, Eth1, ...) are available for use.
To enable & configure, or view a network port:
CHAPTER •
2 VersaSync User Manual Rev. 12
Default IPv4
Default Port, the factory default port
way (default gateway).
Default IPv6
Default Port, the factory default port
way (default gateway).
The General Settings window also displays the IPv4 Address and default
IPv4 Gateway.
1. Navigate to MANAGEMENT > NETWORK: Network
2. The Ports panel on the right side of the screen lists the available Ethernet
ports, and their connection STATUS:
Green: CONNECTED
Yellow: CABLE UNPLUGGED
cable attached)
Red: DISABLED.
Locate the port you want to configure (eth0 or eth1) and click the
GEAR button to enable & configure the port, or the INFO button to
Port: Unless you specify a specific Port to be used as
Port: Unless you specify a specific Port to be used as
(showing the connection speed)
(the port is enabled but there is no
2.8 Configuring Network Settings
eth0 will be used as the gate-
eth0 will be used as the gate-
Setup.
