Back Panel Connector Locations - Oracle X7-8 Service Manual

2. To connect to Oracle ILOM over the network, connect an Ethernet cable to the
Ethernet port labeled NET MGT.
To access the Oracle ILOM command-line interface (CLI) locally using the
3.
management port, connect a serial null modem cable to the RJ-45 serial port
labeled SER MGT.

Back Panel Connector Locations

The following illustration shows and describes the locations of the back panel connectors. Use
this information to set up the server, so that you can access diagnostic tools and manage the
server during service.
The following figure shows the locations of the server back panel connectors and ports.
Callout Description
1 Net management port (NET MGT)
2 Serial management port (SER MGT)
Attach Devices to the Server
System/SMOD Available On
System B – SMOD1 Dual 4-socket systems
only
System B – SMOD1 Dual 4-socket systems
only
