Application Processor Card

This table shows the names and functions of each application processor card.
Table 1-4 Application Processor Card Name and Function
EQUIPMENT FUNCTIONAL
NAME
PN-AP00-A DBM
[For North
America/
Latin America
Only]
PN-AP00-B AP00
PN-AP01 AP01
PN-BRTA BRT
PN-2BRTC BRT
PN-2BRTK BRT
[For UK]
PN-CC01 ETHER
2
NEAX2000 IVS Installation Procedure Manual
ND-70928 (E), Issue 3.0
NAME
Data Base Module Card for WCS Roaming function
One card per WCS system.
Application Processor Card
Provides four S-10 ports and is used for SMDR, Hotel
Printer, CIS, PMS, MCI, CS report functions.
One card per system.
Application Processor Card
Provides one S-10 port and one Ethernet interface port.
Used for OAI function, ID code expansion.
One card per system.
1-line Basic Rate (2B+D) Interface Trunk Card
Accomodates one 2-channel PCM digital lines.
2-line Basic Rate (2B+D) Interface Trunk Card
Accomodates two 2-channel PCM digital lines.
2-line Basic Rate (2B+D) Interface Trunk Card
Accommodates two 2-channel PCM digital lines.
Ethernet Control Card
Used with the PN-AP01 card to accommodate the Ethernet
and transmit/receive a signal of TCP/IP protocol.
10 BASE-T twisted pair cable is connected directly to this
card.
CHAPTER 1 GENERAL INFORMATION
Equipment Name and Function
FUNCTION
