CHAPTER 1 GENERAL INFORMATION
Equipment Name and Function
This table shows the names and functions of installation hardware.
Table 1-2 Installation Hardware Name and Function
EQUIPMENT FUNCTIONAL
NAME
HANGER ASSEM (B)
MOUNTING BRACKET
19" RACK BRACKET (A)
19" RACK BRACKET (B)
I/F BRACKET ASSEM
BASE TRAY ASSEM
Page 12
NAME
Wall Hanger Assembly
One HANGER ASSEM per PIM is required for Wall Mounting
Installation.
Safety Mounting Bracket
Used as an overhead hanger for Floor Standing Installation.
Wire, chain or eyebolts to secure the bracket are to be locally
provided.
To be installed on the top PIM in four or more modules of
stack. It provides 1.1G shockproof construction.
19-inch Rack Mounting Bracket Type A
One bracket is required for one PIM configuration.
One bracket is required for the top PIM in a multiple module
configuration.
19-inch Rack Mounting Bracket Type B
One bracket is required for the bottom module in a multiple
module configuration.
Inter Frame Bracket Assembly
Used to joint the frames in two-frame configuration; for Floor
Standing Installation.
Base Tray Assembly
One BASE TRAY is required per one frame for Floor
Standing Installation of Stationary Equipment.
