CHAPTER 2 INSTALLATION

Cable Running to MDF

CABLE RUNNING TO MDF

Installation of External MDF

• Secure the external MDF onto the floor or the wall.
• Mount the required MDF components.
• If required, install the cable ducts for the cables to be laid between the MDF and the Main
Equipment. In this case, confirm the locations of the cable holes for the Main Equipment.
FRONT
Page 112

Figure 2-43 MDF Cable Hole Location

MODULE
BASE
: CABLE HOLE
2
NEAX2000 IVS Installation Procedure Manual
ND-70928 (E), Issue 3.0
