PN-2ODTB (ODT)

Locations of Lamps, Switches, and Connectors
Lamp Indications
LAMP
COLOR
NAME
BL0, 1 Red
Switch Settings
This card has no switches.
2
NEAX2000 IVS Installation Procedure Manual
ND-70928 (E), Issue 3.0
CHAPTER 3 LAMP INDICATIONS AND SWITCH SETTINGS
• Remains lit when the corresponding circuit is in use.
• Flashes at 60 IPM when the corresponding circuit is in
make-busy state or the system data for this card is not
assigned.
BL1
BL0
CN1
FUNCTION
PN-2ODTB (ODT)
Page 469
