CHAPTER 2 INSTALLATION
SN610/708/709/712/741 ATTCON (DLC)
For SN741 ATTCON, use the modular cord clamp provided with the handset support to dispose
the straight part of the handset modular cord as shown below.
Figure 2-83 Mounting of Handset Support to SN741 ATTCON
MODULAR CORD CLAMP
HANDSET SUPPORT
Page 184
MODULAR CORD
ATTENTION
Contents
Static Sensitive
Handling
Precautions Required
SN741 ATTCON
2
NEAX2000 IVS
Installation Procedure Manual
ND-70928 (E), Issue 3.0
