CHAPTER 2 INSTALLATION
Built-in SMDR (MP)

Figure 2-105 RS NORM-4 CA-A/RS NORM-4S CA-A

See Table 2-7.
D
06 TXC (1)
05 X
04 (RT)
03 X
02 ----
01 X
Page 210
4 m (13.1 ft.) MAX.
06D-TXC (1)
06B-RXC
06A-TXC (2)
05C-DTR
05B-GND
05A-TXD
04B-RXD
04A-RTS
03B-CTS
03A-DSR
02B-GND
02A-DCD
01C-LALB
C B A
X RXC TXC (2)
DTR GND TXD
X RXD RTS
(ST) CTS DSR
X GND DCD
LALB X G
G: GROUND
24-TXC (1)
17-RXC
15-TXC (2)
20-DTR
01-GND
02-TXD
03-RXD
04-RTS
05-CTS
06-DSR
07-GND
08-DCD
18-LALB
13 ----
25 ----
12 ----
24 TXC (1)
11 ----
23 ----
10 ----
22 ----
09 ----
21 ----
08 DCD
20 DTR
07 GND
19 ----
06 DSR
18 LALB
05 CTS
17 RXC
04 RTS
16 ----
03 RXD
15 TXC (2)
02 TXD
14 ----
01 GND
2
NEAX2000 IVS Installation Procedure Manual
ND-70928 (E), Issue 3.0
