NEC NEAX2000 IVS2 Installation Manual page 502

Switch Settings
SWITCH NAME
SW
(Piano Key SW)
OFF
4
3
2
1
ON
2
NEAX2000 IVS Installation Procedure Manual
ND-70928 (E), Issue 3.0
CHAPTER 3 LAMP INDICATIONS AND SWITCH SETTINGS
SWITCH SETTING
NUMBER POSITION
Volume adjustment for No.0 circuit
1, 2
Volume adjustment for No.1 circuit
3, 4
FUNCTION
SWITCH NUMBER
1 2
OFF OFF
ON OFF
OFF ON
ON ON
SWITCH NUMBER
3 4
OFF OFF
ON OFF
OFF ON
ON ON
PN-TNTA (TNT)
CHECK
VOLUME
–10dB
–7dB
–4dB
–1dB
VOLUME
–10dB
–7dB
–4dB
–1dB
