Table 1-5 Line/Trunk Card Name and Function (Continued)
EQUIPMENT FUNCTIONAL
NAME
PN-2DPCB DPC
PN-2ILCA ILC
PN-32IPLA IPELC
PN-4LCC LC
[For Others]
PN-4LCD-A LC
PN-4LCE LC
[For
Australia]
PN-4LCF LC
[For
Australia]
PN-4LCK LC
[For China]
2
NEAX2000 IVS Installation Procedure Manual
ND-70928 (E), Issue 3.0
NAME
2-line Data Port Controller Card
Used for the intra-office or inter-office digital data transmission
on nailed down connection.
Accommodates maximum two DTEs with V.11 (X.21) interface
or V.24/V.28 (S-10) interface.
2-line ISDN Line Circuit Card
Provides a physical interface to ISDN Terminals.
Occupies eight time slots per one card.
32-line IP Line Circuit Card for D
Two cards can be accommodated per F P, maximum eight per
system.
10 BASE-T/100 BASE-TX twisted pair cable is connected
directly to this card.
4-line Analog Line Circuit Card for Single Line Telephones
Loop resistance : Maximum 600 Ω (including telephone set)
Provides Line Test function.
4-line Analog Line Circuit Card for Single Line Telephones
Loop resistance : Maximum 600 Ω (including telephone set)
Provides momentary open and Message Waiting Lamp
control, Line Test functions for each circuit.
Equipped with +80V DC-DC on-board power supply.
4-line Analog Line Circuit Card for Single Line Telephones
Loop resistance : Maximum 600 Ω (including telephone set)
Provides Line Test function.
4-line Analog Line Circuit Card for Single Line Telephones
Loop resistance : Maximum 600 Ω (including telephone set)
Provides Message Waiting Lamp control, Line Test functions
for each circuit, and reverse function for only No. 3 circuit.
Equipped with +80V DC-DC on-board power supply.
4-line Analog Line Circuit Card for Single Line Telephones
Loop resistance : Maximum 600 Ω (including telephone set)
Provides Line Test function.
CHAPTER 1 GENERAL INFORMATION
Equipment Name and Function
FUNCTION
term
IP
