SWITCH NAME
SW1 (DIP SW)
ON
1 2
The figure in the SWITCH NAME column and the position in
column indicate the standard setting of the switch. When the switch is not set as shown by the
figure and , the setting of the switch varies with the system concerned.
NOTE 1: Set the groove on the switch to the desired position.
NOTE 2: When the power is on, flip the MB switch to ON (UP position) before plugging/
unplugging the circuit card.
2
NEAX2000 IVS Installation Procedure Manual
ND-70928 (E), Issue 3.0
CHAPTER 3 LAMP INDICATIONS AND SWITCH SETTINGS
SWITCH SETTING
NUMBER POSITION
ON
1
OFF
ON
2
OFF
FUNCTION
For terminating the transmitting side
of Channels B1 and B2 with 100 Ω.
To remove the terminating resistor
on the transmitting side of Channels
B1 and B2.
For terminating the receiving side of
Channels B1 and B2 with 100 Ω.
To remove the terminating resistor
on the receiving side of Channels
B1 and B2.
in the SETTING POSITION
PN-BRTA (BRT)
CHECK
