CHAPTER 3 LAMP INDICATIONS AND SWITCH SETTINGS
PN-CC01 (ETHER)
Lamp Indications
LAMP
COLOR
NAME
RUN Green
LINK Green
XMT Green
RCV Green
RVP Green
ERR –
Switch Settings
SWITCH
NAME
MB (Toggle SW)
ON
NOTE 1
Page 286
Flashes at 60 IPM while this card is operating normally.
Remains lit when link is established.
Remains lit when it is transmitting the data.
Remains lit when it is receiving the data.
Remains lit only when it is receiving the data with its own IP
address.
Not used
SWITCH SETTING
NUMBER POSITION
UP
DOWN
FUNCTION
FUNCTION
For make-busy
For normal operation
