Lamp Indications
• PN-32IPLA
LAMP
COLOR
NAME
RUN Green
BL Red
LOAD –
PCON –
AUX –
VC3 –
VC2 –
VC1 –
VC0 –
• PZ-M571
LAMP
COLOR
NAME
NALM –
LINK Green
IPDL –
100M Green
TX Green
RX Green
COL Yellow
2
NEAX2000 IVS Installation Procedure Manual
ND-70928 (E), Issue 3.0
CHAPTER 3 LAMP INDICATIONS AND SWITCH SETTINGS
Flash (120 IPM) : This card is operating normally.
Flash (rapidly) : Communication error with MP/FP .
OFF : This card is not operating.
ON : Even one line is busy.
OFF : All lines are idle.
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
ON : Being connected to IP network
OFF : Disconnected to IP network
Not used
ON : Ethernet is operating with 100 Mbps.
OFF : Ethernet is operating with 10 Mbps.
ON : Sending IP data
OFF : Not sending IP data
ON : Receiving IP data
OFF : Not receiving IP data
ON : Detecting IP data collision
FUNCTION
FUNCTION
PN-32IPLA (IPELC)
