SN716 DESKCON (DLC)

(1) MDF Cross Connection
• PN-PW00 Power Option
Figure 2-67 MDF Cross Connection for SN716 DESKCON
NOTE: When using PN-PW00 card, make the installation cable by using the connector
attached with the PN-PW00 card.
PN-8DLC/4DLC
LEN000 (No. 0)
LT00
PN-PW00
08
–48V
07
06
E
05
04
–48V
03
02
E
01
2
NEAX2000 IVS Installation Procedure Manual
ND-70928 (E), Issue 3.0
(PN-PW00 Power Option)
INSTALLATION CABLE
PIM 0
LTC0
J P
1
R0 1
T0 26 26
MDF ROSETTE
NOTE
E
–48V
E
–48V
NOTE
LTC0 (J)
LEN000 1 R0 26 T0
CHAPTER 2 INSTALLATION
SN716 DESKCON (DLC)
TO SN716 DESKCON
6
5
4
3
2
1
MODULAR CONNECTOR
LTC0 (P)
26 T0 1 R0
LTC0 (P)
26 –48V 1 Grd
27 –48V 2 Grd
