Figure 2-66 Mdf Cross Connection For D Term /Dss Console (Long Line) - NEC NEAX2000 IVS2 Installation Manual

CHAPTER 2 INSTALLATION
term
D /DSS Console (DLC)
• Long Line (PN-2DLCB/PN-2DLCN)
Figure 2-66 MDF Cross Connection for D
PN-2DLCB/PN-2DLCN
LEN000 (No. 0)
LEN001 (No. 1)
LT00
Page 162
PIM 0
LTC0
J P
R0 1 1
T0 26 26
R1 2 2
T1 27 27
LTC0 (J)
1 R0 29
LEN000
2 R1 28
LEN001
3 27
4 26
term
/DSS Console (Long Line)
MDF
ROSETTE
LTC0 (P)
T0 26 T0 1 R0
T1 27 T1 2 R1
28 3
29 4
NEAX2000 IVS
term
TO D /
DSS CONSOLE
MODULAR CONNECTOR
2
Installation Procedure Manual
ND-70928 (E), Issue 3.0
