• Mounting PIM to 19-Inch RACK
(1) Mount the PIM with 19-inch RACK BRACKET (A) into the 19-inch RACK.
(2) Secure them with four screws (locally provided).
SCREWS
2
NEAX2000 IVS
Installation Procedure Manual
ND-70928 (E), Issue 3.0
Figure 2-24 Mounting PIM to 19-Inch Rack
CHAPTER 2 INSTALLATION
19-Inch Rack Mounting Installation
19-inch RACK BRACKET (A)
Page 89
