CHAPTER 2 INSTALLATION
19-Inch Rack Mounting Installation
• Connection of 19-inch RACK BRACKET (B)
(1) Place the BASE PLATE on the 19-inch RACK BRACKET (B).
(2) Secure the BASE PLATE with four washers and nuts.
(3) Mount the BASE to the BASE PLATE. (See
(4) Mount the PIM to the BASE. (See
NOTE: Nuts and washers are attached to the 19-inch RACK BRACKET (B).

Figure 2-25 Connection of 19-Inch RACK BRACKET (B)

19-inch RACK BRACKET (B)
Page 90
Figure
BASE PLATE
Figure 2-13.)
2-14.)
NUT
WASHER
NEAX2000 IVS
2
Installation Procedure Manual
ND-70928 (E), Issue 3.0
